Home > Products > Precision Shearing Machine > MECHINICAL SHEARING MACHINE
MECHINICAL SHEARING MACHINE
- 500 Set / Sets per Month
- any port at china
- T/T
-
TOP THIS SHEARING MACHINE QH11D-3.2*1300
-
TOP THIS SHEARING MACHINE QH11D-3.2*1300 3.2*1250 3.2*1300
-
TOP SELLING ON THIS SHEARING MACHINE QH11D-3.2*1300 3.2*1250 3.2*2000
-
TOP SELLING ON THIS SHEARING MACHINE QH11D-3.2*1300 3.2*1250 3.2*2500
-
TOP SELLING ON THIS SHEARING MACHINE QH11D-3.2*1300 3.2*1250
-
TOP SELLING ON THIS SHEARING MACHINE QH11D
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | oem | Model Number: | nc cnc |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
1300
Specification
Parameter
| QH11D- 3.5×1250 QH11D- 3.5×1300 | QH11D-
3.2×1500 | QH11D-
3.2×2000 | QH11D-
3.2×2500 | QH11D-
2.5×2500 | ||
1 | Shearing Thickness | 3.5mm | 3.2mm | 3.2mm | 3.2mm | 2.5mm | |
2 | Shearing Width | 1250/ 1300mm | 1500mm | 2000mm | 2500mm | 2500mm | |
3 | Shearing Angle | 1°30' | 1°30' | 1°30' | 1°20' | 1° | |
4 | Number of Stroke | 47n/min | 47n/min | 47n/min | 47n/min | 47n/min | |
5 | Max. Number of Cuttings Per Minute | 10n/min | 10n/min | 10n/min | 10n/min | 10n/min | |
6 | Front-gauge Range | 900mm | 900mm | 900mm | 900mm | 900mm | |
7 | Back-gauge Range | 650mm | 650mm | 650mm | 650mm | 650mm | |
8 | Height of Table | 800mm | 800mm | 800mm | 800mm | 800mm | |
9 | Motor | Type | YEJ132S-4 | YEJ132S-4 | YEJ132M-4 | YEJ132M-4 | YEJ132M-4 |
|
| Output | 5.5Kw | 5.5Kw | 7.5Kw | 7.5Kw | 7.5Kw |
|
| Speed | 1430r/min | 1430r/min | 1430r/min | 1430r/min | 1430r/min |
10 | Overall
Dimensions | Length | 1860mm | 2110mm | 2624mm | 3124mm | 3124mm |
|
| Width | 2100mm | 2100mm | 2100mm | 2100mm | 2100mm |
|
| Height | 1180mm | 1180mm | 1180mm | 1180mm | 1180mm |
11 | Net Weight | 1440kg | 1560kg | 1800kg | 2100kg | 2000kg | |
