Home > Packaging & Printing > Printing Machinery > Digital Printing Machine > High Resolution 6 Color Pheaton Spt 508gs Heads Digital Printing Machine

High Resolution 6 Color Pheaton Spt 508gs Heads Digital Printing Machine

Name: High Resolution 6 Color Pheaton Spt 508gs Heads Digital Printing Machine
Brand: Phaeton
SKU: 122924515
Availability: InStock

Guangzhou Caixu Digital Technology Ltd.

High Resolution 6 Color Pheaton Spt 508gs Heads Digital Printing Machine thumbnail-1

High Resolution 6 Color Pheaton Spt 508gs Heads Digital Printing Machine photo-1

US$ 10,000 - 15,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Plate Type:

Flatbed Printer

Place of Origin:

Guangdong, China

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

GUANGZHOU

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Plate Type Flatbed Printer

Place of Origin Guangdong, China

Brand Name Phaeton

Model Number UD-3286Q

Usage Card Printer, Cloths Printer, Label Printer, Paper Printer, Other, Card Printer, Cloths Printer, Label Printer, Paper Printer, banner machines

Automatic Grade Automatic

Voltage 220V

Gross Power 1500W

Dimensions(L*W*H) L4,650 x W970 x H1,550mm

Weight 582KG

Certification CE Certification

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Phaeton NEWLY printing machine UD-3286Q

1, Equipped with 4 /6 SPT508GS print heads

2, Ink level sensor. Auto-pumping

3, Anti-Clogging Flash Function & Capping System

4, Individual color cleaning minimizes the waste of the ink

5, 3 way intelligent heater (pre/print/post) helps bring more vivid output

6, The entire printing platform and the girder are made of the alloy-aluminum which is strong and flat

Parametre List

Model	UD-3286Q
Print Head	SPT 508GS
Number of Print Head	6 heads
Max Printing Width	3200mm
Printing Speed (m2/hr)	Print Mode	Standard Output(m/h)
	D	2 pass 91
	S	3 pass 61
	Q	4 pass 46
	HQ	6 pass 31
	C	8 pass 23
Ink	Type	Solvent ink & ECO solvent ink
	Color	(C,M,Y,K)or (C,M,Y,K,LC,LM)
	Capacity	1L or 5L per Main Tank of Each Color
	Ink supply system	Low Ink sensor ,Auto or Manual Ink Supply System
Media	Width	Max 3300mm
	Type	Vinyl, Window Film, Polyester, Flex, Back-lit Film, etc
Auto Media Feeding System	Equipped Max media weigh 80kg
Auto Cleaning System	Individual Positive Pressure Cleaning, Anti-clogged Flash Function&Capping System
Pre-heating & Drying System	Equipped
Clamp	Equipped
Print Interface	USB2.0
Print Head Height	2-10mm from media
Rip Software	Ultraprint, Maintop, Photoprint, Shiraz, Wasatch
Input Power	AC220v, 50HZ/60HZ
Machine Dimension	L4,500 x W905 x H1,260mm / 362KG
Package Dimension	L4,650 x W970 x H1,550mm / 582KG
Requirement	Temperature: 20-28 degree, Humidity: 40% - 60%

Detailed Images

Pictures to reference:

Strong body of UD-3286Q

Light equited, convienice to check the printing status .

AC serve motor make the printing more faster and stable .

Printer was packed by the wooden box with great protection and send to customers .

Packaging & Shipping

Associated Products

You may interesting in this print heads . We provide 100% original and brand new products.

Our Services

Technical Support :

1. Any question we ensure to try our best to help you .By email ,vedio ,TEL, long-distance computer control and so on . We company has the experts and professional skill team for machine who has more than 10 years experience about the printers. Free trainning is avaliable .

2. All kinds of original spare parts for the machine to ensure your machine running smoothly

What is more , all the printers have one year warranty . During the warranty, if any problems of the parts , you can send us back to repair or exchange .

This month our company has discount for the machine . And the shipping cost will be 30% off.Please feel feel to contact us.

Contacting information :

Name : Kate

Tel: 0086 020 32053300

Cellphone and whatsapp : +0086 13580499694

Skype: kate_4724
