Precise 4x2 Hdmi Matrix With Spdif Optical Output Ultra HD 4KX2K

Precise 4x2 hdmi matrix with spdif optical output Ultra HD 4KX2K (HLHM0404A)

Specification:

HDMI 4x4 single Cat5e/6 extender output HD video matrix, which can accept 4 HD HDMI signal inputs, as well 4 HD HDMI and 4 Cat5e/6 RJ45 outputs can select any one of 4 video inputs. This 4x2 HDMI matrix can support maximum 1080p 3D or 1080p 60fs resolution, and also include a 4x4 dual direction IR matrix companion with video matrix extender output. The 4*2 HDMI matrix with spdif optical output is fully compatible with HDMI 1.3c (HDMI 1.4 3D) and HDCP 1.3.

Main features:

HDMI 1.3 spec and HDMI 1.4 3D supports

HDMI HDCP1.3 compatible

True 4 by 4 HDMI matrix, allow 4 outputs could select the same or different HDMI source simultaneously

Each group of matrix output includes one HDMI and RJ-45 extender port; both can output HD video simultaneously.

Cat5e/6 extender outputs support power over UTP, receiver side don’t need external DC adapter.

It can supported resolutions 1080p/1080i/720p/576p/480p/576i/480i

It can support audio format PCM, Dolby®-AC3, DTS®7.1, DSD

HPD and CEC supports

Both emitter and receiver 4x4 IR matrix embedded with local IR control

Auto remembering last power-off matrix status and auto skip for unconnected inputs when power-on initialization

EDID dynamic mixing management with maximum compatibility

Cat5e/6 extender port support EDID call back

Multi-mode control by LAN, RS232, local IR remote, Cat5e/6 extender side IR receiver or panel button.

ESD protection level HBM ±8 kV(Contact Discharge)for any input and output port

Industrial metal case, easy to install

Parameters:
