Din2391 Hydraulic steel pipe and cold drawn weld tube ST52
- 500 Metric Ton / Metric Tons per Month
- Yantai/Qingdao
- T/T
You May Like
-
Cold drawn honed 27SiMn alloy tube oq:10mT
-
Seamless Hot rolled galvanized steel pipe MOQ:5MT
-
Lowest price Precision carbon Seamless cold rolled 50mm steel pipe
-
MIld Hot rolled astm 1020 smls steel pipe Competitive price
-
Seamless Astm a53 sch 40 steel pipe competitive price
-
aisi 1020 Cold drawn seamless steel pipe Competitive Price
Product Details
Thickness | 2, 30 | Section Shape | Round | |
Outer Diameter | 30 - 250 mm | Place of Origin | Shandong, China | |
Secondary Or Not | Non-secondary | Application | Other, Hydraulic Pipe, Hydraulic cylinder,automobile,oil drilling, textile machinery | |
Technique | Cold Drawn | Certification | Other, ISO 9001 2008 | |
Surface Treatment | Other, According to the custome's need | Alloy Or Not | Non-alloy |
Product Description
Din2391 Hydraulic steel pipe and cold drawn weld tube ST52
What we want to say:
Dear Sir/Madam, Welcome~
We are Yantai Xinpeng Steel Pipe Co.,Ltd
♦ Professional tube manufacturer which have over 20years experience
♦High reputation in tube world benefit by competitive price, quality and service.
♦ Supply all kinds of steel pipes such as:
√ hot rolled/cold drawn seamless steel pipes
√ honed and skived pipes
√ cold drawn welded tubes(DOM tubes)
♦ Our Website: http://ytxinpeng.en.china.cn
About our productions:
Production Details: | |||||
Grade: | 20#(CK20,AISI1020),45#(CK45,AISI1045),Q345,ST52(16Mn,Q345D), 42CrMo,25Mn (STKM13C-T),27SiMn.etc cold drawn seamless pipes | ||||
ID: | 50-250mm | ||||
ID tolerance: | H8,H9 | ||||
Surface roughness: | Ra 0.02—0.4μm | ||||
Final supply condition: | cold drawn and stress-relieved(BK+S) | ||||
Machining allowance: | 0.5-1.5mm | ||||
Wall thickness: | 10%×ID |
<
Mechanics performance: | ||||
Material | Tensile strength | Yield strength | Elongation | Hardness |
CK20/20#/AISI1020 | >520 N/ mm2 | >375 N/mm2 | >15% | >85HB |
CK45/45#/AISI1045 | >600 N/ mm2 | >520 N/ mm2 | >15% | >85HB |
ST52/16Mn/Q345D | >600 N/ mm2 | >520 N/ mm2 | >15% | >85HB |
25Mn/STKM 13C-T | >600 N/ mm2 | >530 N/ mm2 | >15% | >85HB |
Variety : | |||||
Processing | Cylinder Diameter | Straightness | Size Accuracy | W.T/mm | Inner Bore Roughess |
Cold drawn/cold rolled | ID30-250 | 0.3 | H9-H11 | ±10% | 0.4~1.6um |
Honed tube | ID50-250 | 0.3 | H7-H9 | ±10% | <0.4um |
Tolerance on ID: | ||
No. | Inside diameter (mm) | ID machining allowance (mm) |
1 | 300-80 | 0.5-0.8 |
2 | 81-125 | 0.7-1.1 |
3 | 125-200 | 0.9-1.2 |
4 | 200-250 | 1-1.5 |
Other dimension can be customize |
About our work flow:
About our package:
About our test equipment:
About our company:
Yantai Xinpeng Steel pipe co,.ltd.
Located in Yantai, a beautiful coastal city in Jiaodong Peninsula, our company is in the (APEC) Science & Technology Industrial Park, urban area of Yantai, with convenient transportation.
Established in December 1992, with registered capital of 5 million yuan and plant and office space of 12,000 square meters, covering an area of 20,000 square meters , our company mainly produces various specifications of cold drawn,rolled precision steel tube,hydraulic cylinder tube and SRB Tube, which are widely used in such industries as hydro-cylinder, automobile, engineering machinery, textile machinery, printing machinery, oil drilling, etc. Our company is also the distributor of several domestic well-known steel tube plants in Shandong, and mainly distributes seamless steel tubes of all kinds of materials.
Distribution, production,agency services:
1. Distribution: Various specifications and materials of seamless steel tubes produced by steel tube plants, such as Baosteel, Baogang Group, Hubei Xinyegang Steel, Tianjin Pipe, Hu’nan Hengyang Valin Steel Tube, PanGang Group Chengdu Iron & Steel, Shandong Yantai General Steel Tube Plant, Yantai Lubao, etc.
2. In October 2002, Shandong Penghui Hydro-cylinder Co., Ltd. was established, and 1 set of 250 ton hydraulic precision cold drawn unit was introduced to produce various specifications of cold drawn precision steel tubes, which are widely used in such industries as hydro-cylinder, automobile, engineering machinery, textile machinery, printing machinery, oil drilling, etc.
3. Agent service: Hydro-cylinder used high precision cold drawn welded tube (DOM) produced by Italy Marcegaglia.
Adhere to the business concept of “integrity”, “the Xinpeng Staff” are dedicated to building the brand of Xinpeng Steel Tube with high quality products, and preserving the enterprise image of Xinpeng Steel Tube with perfect service and supreme credibility.
We warmly welcome new and old customers to our company to negotiate business, sincerely cooperate with each other, and realize mutual prosperity and common development.
About our certificate:
About our business partner:
About our deliver conditions:
1. Standard packing with plastic caps and strapped bundles.
2. Commercial length 2000~10500mm,custom lengths upon request
3. Surface protection
About our service:
1. Cargo track service during transporting and feedback service after cargo is loaded on board
2. Flexible terms of payment by T/T and L/C
3. Big discount for repeat customers
4. Smooth delivering procedure
