Ultrasonic Sealing Machine (CE Certified)

Ultrasonic Sealing Machine (CE certificated)

Model: MS-50S

1.Machine picture and samples

2. Characteristics

Power Supply: 220V±5V 50Hz (60Hz)
Working Frequency: 20KHz
Output Frequency: 1500W
Working Speed: 0-18M/min
Effective Breadth: 10MM
Equipped Pattern Mould: 12MMxØ51MM; 50MMxØ51MM
Materials Suitable: for Hot Fusibility, for example: polyester, nylon, chemical and non-woven fabrics

Packing Size: L (125cm)x W(61cm)x H(129cm)

Total weight: 140 Kg

3. Basic components:
1. New type intellectual ultrasonic generator
2. Built-upper ultrasonic transducer
3. Pneumatic welding head lifting system
4. Rolling mould adjusting structure and arranging system
5. Special framework design with multi practical functions.
6. Speed modulating system with single circuit motor

4. Characteristics:
1. Applied to the non-pin seam of chemical fiber fabrics, non-woven fabrics, thermo-melt fabrics, taking the place of sewing or down-press type welding, limitless continuous welding function, with solid weld, beautiful and high work efficiency.
2. Multi-functional frame work system with the application of straight line seam, turn seam and cylinder joining..
