XK7132 CNC Machining Center
- 100 Set / Sets per Month
- Qingdao Tianjin Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Cheap Machine Centre For Sale
- VB 610 Vertical Metal Band Saw with Proven Solid Construction, including Band Saw Blade Welder
- VB 510 Vertical Metal Band Saws with Proven Solid Construction, including Band Saw Blade Welder
- VB 410 Vertical Metal Band Saw with Proven Solid Construction, including Band Saw Blade Welder Quality Choice
- VB 360 Vertical Metal Band Saws with Proven Solid Construction, including Band Saw Blade Welder
- Semi-Automatic Horizontal Miter Band Saw HBG 280
Product Details
Condition: | New | Type: | Horizontal | Place of Origin: | Shandong, China |
Brand Name: | DATONG | Model Number: | XK7132 | Power(W): | 3.7KW |
Dimension(L*W*H): | 2250*2200*2400 mm | Weight: | 2800kg | Certification: | ISO CE |
Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications | XK 7132 | |
Table size | 320X500mm | |
Longitudinal travel | 450mm | |
Cross travel | 300mm | |
Vertical travel | 430mm | |
Spindle motor | 3.7KW | |
Spindle range | 8000r/min | |
Spindle taper | BT30 | |
X/Y/Z axis rapid travel | MITSUBISHI | 36/36/24m/min |
FANUC | 24/24/24m/min | |
X/Y/Z axis cutting feed rate | 10 m/min | |
Spindle nose to table surface | 160 -590 mm | |
Spindle center to column surface | 355 mm | |
Positioning accuracy | 0.013mm | |
Repeatability accuracy | 0.008mm | |
Machine dimensions (L*W*H) | 2250×2200×2400 mm | |
Net weight | 2800kg |
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
