Metal Circular Saw KHK 350 Semi-automatic Circular Saw with pneumatic part clamping Quality Choice
- 200 Set / Sets per Month
- Tianjin.Qingdao.Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Horizontal Miter Band Saw SBS 260 Flexible, proven and easy to handle
- Horizontal Miter Band Saw SBS 210 Flexible, proven and easy to handle
- Horizontal Dual Miter Band Saw SBS 310 Workshop band saw offers high flexibility and frame swivels to both sides for dual miter
- Horizontal Band Saws HB 320 BS Highly reliable Horizontal Band Saws with comfortable miter adjustment
- HB 280 B Horizontal Band Saws Highly reliable Horizontal Band Saws with easy miter adjustment
- Semi-Automatic Band Saw HB 1020 L High-Performance Band Saw for very large workpieces
Product Details
Condition: | New | Type: | Band Saw | Use: | Metal Cutting |
Style: | Vertical | Place of Origin: | Shandong, China | Brand Name: | datong |
Model Number: | KHK 350 | Usage: | Cutting | Voltage: | 400V |
Power(W): | 1,5 kW | Dimension(L*W*H): | 1.100x640x1.680 mm | Weight: | 310 kg, 310 kg |
Certification: | CE ISO | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Metal Circular Saw KHK 350
Feature:
1.Quick-action vise with pneumatic clamping reduces setup time
2.Automatic sawing process with infinitely variable feed speed
3.Two saw blade speeds for optimum cutting results in different materials
4.Miter cuts up to 45°
5.Adjustable saw stroke results in shorter cycle times when cutting small diameter parts
6.Gears running in oilbath
7.Includes base and coolant system
Specification:
Working area Max. saw blade diameter Spindle speeds Width of vise Air supply Air consumption | 350 mm 38, 19 rpm 145 mm 6 bar 120 l/min |
---|---|
Cutting capacities Cutting capacity 90° (flat) Cutting capacity 90° (square) Cutting capacity 90° (round) Cutting capacity 45° (flat) Cutting capacity 45° (square) Cutting capacity 45° (round) | 130x110 mm 130 mm 140 mm 120x95 mm 120 mm 120 mm |
Drive capacity Motor rating main drive Supply voltage | 1,5 kW 400 V |
Measures and weights Overall dimensions (length x width x height) Weight | 1.100x640x1.680 mm 310 kg |
Standard Equipment:
quick-action vice, linear stop, foot pedal, base, coolant system
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
