Swivel Head Type Multipurpose Milling Machine X5746
- 50 Set / Sets per Month
- qindao.tinajin.shanghai
- T/T L/C D/P D/A Credit Card PayPal
- Swivel Head Type Multipurpose Milling Machine X6432
- Swivel Head Type Multipurpose Milling Machine XL6436
- Swivel Head Type Multipurpose Milling Machine XL6432
- X2014 Heavy Duty Gantry Milling Machine For Sale
- New Design Mini Vertical CNC Milling Machine XK7110C/D For Sale Quality Choice
- Vertical Turret Milling Machine X6325Z for sale
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | DATONG |
Model Number: | X5746 | Type: | Universal | CNC or Not: | Normal |
Voltage: | 220v/380v | Power(W): | 5.5kw | Dimension(L*W*H): | 1835*2362*2090mm |
Weight: | 3200kg | Certification: | CE ISO9001 | Warranty: | 12 Months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Swivel Head Type Multipurpose Milling Machine X5746
Feature:
1.Easy control
2.Ballscrews can be ordered instead of standard leadscrews at special request
3.Ram milling machine
Specification:
Model | X5746 | X5750 |
Table size | 460*1235mm | 500*1600mm |
T-slots(NO./width/pitch) | 5*18*80mm | |
Table travel (X/Y/Z) | 900*650*450mm | 1200*700*500mm |
Swivel angle of milling head | 360° | |
Spindle taper | ISO40 | ISO50 |
Spindle speed range | (27) 30-2050rpm | |
Table feed(X/Y/Z) | 10-1000/10-1000/6-640mm/min | 10-1000/10-1000/5-500mm/min |
Table rapid speed | 2200/2200/1100 | |
Distance between spindle nose and table surface | 32-482mm | 25-525mm |
Distance from spindle center line to column | 47-697mm | 55-755mm |
Main motor power | 5.5kw | 7.5kw |
Feed motor | AC servo motor X/Y:15NM; Z: 18NM | |
Max load | 800kg | 1800kg |
Overall size | 1835*2362*2090mm | 2475*2260*2180mm |
Net weight | 3200kg | 4000kg |
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
