metal sandwich panel production line

Specifications

1.PLC computer control
2.no noise,no shake
3.hydraulic system,long operating
4.easy operation
5.maintenance-free

Glazed Tile Roll forming line



     Our factory is specialized in manufacturing color steel forming machinery,C&Z purlin machine,archaic glazed tile forming machine,steel structural floor panel roll forming machine,sandwich panel roll forming machine,highway guardrail forming machine and other cold roll forming machines.



1.The chart of process flow:

  Decoiling--active feeding---forming---measuring lengh---cutting---product to stand



 2.Main equipment:

 Decoiler,main forming machine,hydraulic cutting,electric system(plc),hydraulic system,product stand.



 3.Technical parameters







thickness:0.3--0.8mm



main forming machine

A.Shaft material:45# steel,bearing steel outer diameter 85mm

B.Main motor power:5.5kw

C.Forming speed:8--10m/min

D.Voltage:380v,50hz

E.Roller station:15















Terms:

1.Delivery:in stock

2.Package:export standard package for container

3.Payment:TT (30% by TT in advance,70% by TT after you inspect machine we need)

4.Delivery date:within 30 working days after receiving deposit

5.Products Warranty:12 month,and we will provide the technical support for whole life of the equipment.
