Found brand machinery VMC850 CNC vertical machining center
- 500 Set / Sets per Month
- Qing Dao/Shang Hai
You May Like
-
High precision Chinese brand VMC850 CNC vertical machining center
-
Multi purpose Economic type VMC850 CNC vertical machining center
-
Multi function Hot sale china VMC850 CNC vertical machining center
-
Hot sale china Multi purpose VMC850 CNC vertical machining center
-
Economic type brand price VMC850 CNC vertical machining center
-
Hot sale china , metal cutting china VMC850 CNC vertical machining center
Product Details
| Condition | New | Type | Vertical | |
| Place of Origin | Shandong, China | Brand Name | FINDMC | |
| Model Number | VMC850 | Voltage | 380v, 415v or others | |
| Power(W) | AC servo 7.5/11 KW | Dimension(L*W*H) | 2500*2600*2300mm | |
| Weight | 5500 Kg | Certification | CE ISO9001 | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Features of VMC850 vertical machining center, CNC milling machine:
1.Machine frame with linear guides in an extra-wide configuration, Robust construction for efficient machining.
2.Linear guide system for rapid feeds up to 10 m/min.
3.High-precision preloaded ball screws on all 3 axes.The 4th axis is optional.
4.Funnel type 20-station tool changer for quick and precise tool changes (as Optional).
5.Chip conveyor and purge system for optimum chip removal.
6.Easy accessibility of work table for easy setup and tooling
7.Enclosed work space ensures safe and contamination-free work.
8.Operating system: Mitsubishi, Fanuc and Siemens
9. mainly applicable to processing board, plate, shell mold and small complex parts.
10.able to mill steel,copper,aluminum,wood and plastic etc.
11.can continuously complete drilling,milling,tapping,reaming,expanding and other processess at one clamping.
VMC 850 vertical machining center, CNC milling machine
cnc vertical machining center |
| VMC850 | |
Table | Area | Unit | 1000×500 mm |
| T-slot | mm | 5-18-100 |
| Max. load | kg | 500 |
Travel | Moving range X, Y, Z | mm | 850×500×500 |
| Spindle nose to table surface | mm | 150~650 |
| Spindle center to column guideway | mm | 560 |
Feed
| Rapid feed speed X, Y, Z | m/min | 30/30/24 |
| Feed speed X, Y, Z | mm/min | 10~10000 |
Spindle
| Taper |
| BT40 |
| Speed | r/min | (AC servo) 40~6000 |
| Power | kW | AC servo 7.5/11 |
Tool magazine with capacity |
| qty | 16/24 |
Accuracy | Positioning accuracy | mm | ±0.005/300 JIS |
| Re-positioning accuracy | mm | ±0.003/300 JIS |
Overall dimension | mm | 2500*2600*2300 | |
Machine weight | kg | 5500 | |
Standard accessories:
- adjusting sizing block
- Inner hexagon spanner
- Wrench
- Foundation bolts
- Hex. nut
- Washer
Optional accessories suit the CNC vertical milling machine, VMC850 CNC vertical machining center
Packaging & Shipping
Machine: VMC 850 vertical machining center
Type of package: Plywood case
Packing dimension: 289*228*255cm N.W./G.W.: 5500/6000KGS
40 High container: 4sets
Delivery time: 45-60days in usual
Payment terms: TT30% down payment, TT70% before the delivery date. L/C at sight
Port: Qingdao/Shanghai
1. Technical support online service provided.
2. Technical files service provided.
3. On-site training service provided.
4. All of the questions will be replied within 24 hours
5. Warranty period: one year
During warranty period, if you have any parts broken because of qulity problem,we will supply to you free of charge by express.
Out of warranty period, if you have any question, you can contact with us, we will supply our best service to you as usual.
Find Machinery supplys a wide range of products and service to its global customers, including VMC, miling machine, radial drilling machine, CNC engrving machine, HSS annular cutter, TCT annular cutter, rail cutter, steel tools and non-sparking tools. They are widely sold to more than 50 countries and areas in Europe, America, and Middle-east, relying on the reliable product quality, reasonable price and perfect after-sales service system.
Find Machinery follows the concept of credit management cooperation and win-win strategy, and it has good comments from society and clients. Here we sincerely hope to cooperate with you to create a bright future.
