Bright Zinc Die-casting Distribution Cabinet Safe Lock for Cabinet

the black or bright zinc die-casting   distribution cabinet safe lock

1.black zinc electrical cabinet door panel lock,three-point lock

2.Model:SW-731-1 cabinet lock

3.ZDC body.

4.Material and Surface Treatment:

Housing and  Lock-back: Zinc alloy die cast,  matt black powder coated.

Large Core and Small Core: Zinc alloy die cast,  bright chrome plated .

Shaft, Lock-tongue, Insert: Zinc alloy die cast,accessory with zinc plated.

Key: Zinc alloy die cast, nickel plated, or nickel-plating brass key with ABS handle.

Installation, Cam Location: Cold rolled steel accessory with zinc plated.

Pin, Locking Screw : Rolled steel accessory with zinc plated.

Key-ring, Spring, Torsion Spring: Carbon steel wire, passivation.

Cap, Dustproof Cap: 304 stainless steel, passivation.

Insert-panel: Brass , yellow.

5.IP Grade: IP65.

6.Application:

(1)    Large pop-up cabinet locks

(2)    Two types for choosing: rounded-corner and square corner.

(3)    Both for left-hand and right-hand use by changing the locating plate.

(4)    It apply to lighting box, controlling switch-board , fire-fighting cabinet, telecom equipment cabinet, electricity cabinet and other kinds of cabinets .........
