COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory)

Wuxi Co-Power Technology Co., Ltd. Gold Verified Supplier
5Yrs
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) thumbnail-1
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) thumbnail-2
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) thumbnail-3
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) thumbnail-4
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) thumbnail-5
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) thumbnail-6
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) photo-1
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) photo-2
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) photo-3
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) photo-4
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) photo-5
COPOWER320 4X4WD ATV With Rubber Track System (Direct Factory) photo-6
US$ 2,400 - 2,600 MOQ: 2 Pieces
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Engine Type 4 Stroke
Transmission Type Automatic
Transmission System Shaft Drive
Certification ECE
Brand Name CO-POWER
Place of Origin Jiangsu, China
Model Number COPOWER320 4X4WD ATV

Specifications

COPOWER320 4X4WD ATV with rubber track system and our snowmobile Engine.





COPOWER320 4X4WD ATV with rubber track system (Direct factory)COPOWER320 4X4WD ATV with rubber track system (Direct factory)





COPOWER320 4×4WD Double Snow ATV

AT VFINAL DRIVE SYSTEMShaft / 4WD & 2WD
TRANSMISSIONAutomatic CVT with H-L-N-R
SHOCK ABSORBERFour-wheel independent suspension
The snow characteristicsFour-snow Rubble Tracks Can be choosed
MAX.SPEEDwheel:70KM/h;Track:45KM/h
BRAKE FRONT&REARHydraulic disc brake
BRAKE DISTANCE7m @ 30km/h
BATTERY12V/18AH
FUEL90# unleaded gasoline
FUEL CAPACITY19L
MAX.LOAD(kgs/lbs)180kg
FRONT& REAR TIRE25×8-12/25×10-12/25
OVERALL2250×1180×1230
PACKAGE40HQ`(SET)30pcs
SEAT HEIGHT(mm)900mm
NET WEIGHT(kgs/lbs)305kgs
En gIneENGINE TYPE4 Stroke,with balance shaft,Water Cooled
MAX.POWER(KW/rpm)15.2KW @ 7000rpm
MAX.TORQUE(NM/rpm)28N.M @ 5500rpm
CYLINDER NO.Single Cylinder
BORE STROKE78mm × 65.2mm
DISPLACEMENT312ml
COMPRESSION RATIO10.2:1
ENGINE OIL1.4L
GearBox   OIL0.5L
SPARK PLUG(DR8EA
STARTINGElectric Start & Hang Pull
IGNITIONC.D.I
