Home > Products > Pipe Series > API 5CT L80 Tubing
API 5CT L80 Tubing
- 5000 Ton / Tons per Month
- China seaport
- T/T
Product Details
| Thickness: | 30, 300 | ||||
| Section Shape: | Round | Outer Diameter: | 20 - 30 mm | Place of Origin: | Shaanxi, China |
| Secondary Or Not: | Non-secondary | Application: | Oil Pipe | Technique: | Hot Rolled |
| Certification: | API | Special Pipe: | API Pipe | Alloy Or Not: | Is Alloy |
Product Description
API 5CT L80 Tubing :
Standard: API 5CT
Grade: J55, K55, L80, N80,L80, C90, T95, P110, Q125
Connection Type: NU,EU,IEU
Size Destination: 1.05"--4 1/2''
Wall thickness:2.87mm~16.13mm
Length: R1, R2, R3
Also we can supply you pup joint and coupling (coupling stock and coupling blank) for tubing and Casing, as well as for weld pipe.
Size | Linear Mass lb/ft | Outside Diameter | Wall thickness | Type of end-finish | ||||||||
Grade | ||||||||||||
Non Upset | Ex-Upset | In | mm | mm | H-40 | J-55 | L-80 | N-80 Type1,Q | C-90 | T-95 | P-110 | |
1.050” | 1.14 | 1.20 | 1.050 | 26.67 | 2.87 | PNU | PNU | PNU | PNU | PNU | PNU | -- |
1.48 | 1.54 | 1.050 | 26.67 | 3.91 | PU | PU | PU | PU | PU | PU | PU | |
1.315” | 1.70 | 1.80 | 1.315 | 33.40 | 3.38 | PNUI | PNUI | PNUI | PNUI | PNUI | PNUI | -- |
2.19 | 2.24 | 1.315 | 33.40 | 4.45 | PU | PU | PU | PU | PU | PU | PU | |
1.660” | 2.09 | -- | 1.660 | 42.16 | 3.18 | PI | PI | -- | -- | -- | -- | -- |
2.30 | 2.40 | 1.660 | 42.16 | 3.56 | PNUI | PNUI | PNUI | PNUI | PNUI | PNUI | -- | |
3.03 | 3.07 | 1.660 | 42.16 | 4.85 | PU | PU | PU | PU | PU | PU | PU | |
1.900” | 2.40 | -- | 1.900 | 48.26 | 3.18 | PI | PI | -- | -- | -- | -- | -- |
2.75 | 2.90 | 1.900 | 48.26 | 3.68 | PNUI | PNUI | PNUI | PNUI | PNUI | PNUI | -- | |
3.65 | 3.73 | 1.900 | 48.26 | 5.08 | PU | PU | PU | PU | PU | PU | PU | |
4.42 | -- | 1.900 | 48.26 | 6.35 | -- | -- | P | -- | P | P | -- | |
5.15 | -- | 1.900 | 48.26 | 7.62 | -- | -- | P | -- | P | P | -- | |
2.063” | 3.24 | -- | 2.063 | 52.40 | 3.96 | PI | PI | PI | PI | PI | PI | -- |
4.50 | -- | 2.063 | 52.40 | 5.72 | P | P | P | P | P | P | P | |
2 3/8” | 4.00 | -- | 2.375 | 60.33 | 4.24 | PN | PN | PN | PN | PN | PN | -- |
4.60 | 4.70 | 2.375 | 60.33 | 4.83 | PNU | PNU | PNU | PNU | PNU | PNU | PNU | |
5.80 | 5.95 | 2.375 | 60.33 | 6.45 | -- | -- | PNU | PNU | PNU | PNU | PNU | |
6.60 | -- | 2.375 | 60.33 | 7.49 | -- | -- | P | -- | P | P | -- | |
7.35 | 7.45 | 2.375 | 60.33 | 8.53 | -- | -- | PU | -- | PU | PU | -- | |
2 7/8” | 6.40 | 6.50 | 2.875 | 73.03 | 5.51 | PNU | PUN | PNU | PNU | PNU | PNU | PNU |
7.80 | 7.90 | 2.875 | 73.03 | 7.01 | -- | -- | PNU | PNU | PNU | PNU | PNU | |
8.60 | 8.70 | 2.875 | 73.03 | 7.82 | -- | -- | PNU | PNU | PNU | PNU | PNU | |
9.35 | 9.45 | 2.875 | 73.03 | 8.64 | -- | -- | PU | -- | PU | PU | -- | |
10.50 | -- | 2.875 | 73.03 | 9.96 | -- | -- | P | -- | P | P | -- | |
11.50 | -- | 2.875 | 73.03 | 11.18 | -- | -- | P | -- | P | P | -- | |
3 1/2” | 7.70 | -- | 3.500 | 88.90 | 5.49 | PN | PN | PN | PN | PN | PN | -- |
9.20 | 9.30 | 3.500 | 88.90 | 6.45 | PNU | PNU | PNU | PNU | PNU | PNU | PNU | |
10.20 | -- | 3.500 | 88.90 | 7.34 | PN | PN | PN | PN | PN | PN | -- | |
12.70 | 12.95 | 3.500 | 88.90 | 9.52 | -- | -- | PNU | PNU | PNU | PNU | PNU | |
14.30 | -- | 3.500 | 88.90 | 10.92 | -- | -- | P | -- | P | P | -- | |
15.50 | -- | 3.500 | 88.90 | 12.09 | -- | -- | P | -- | P | P | -- | |
17.00 | -- | 3.500 | 88.90 | 13.46 | -- | -- | P | -- | P | P | -- | |
4” | 9.50 | -- | 4.000 | 101.60 | 5.74 | PN | PN | PN | PN | PN | PN | PU |
-- | 11.00 | 4.000 | 101.60 | 6.65 | PU | PU | PU | PU | PU | PU | PU | |
13.20 | -- | 4.000 | 101.60 | 8.38 | -- | -- | P | -- | P | P | -- | |
16.10 | -- | 4.000 | 101.60 | 10.54 | -- | -- | P | -- | P | P | -- | |
18.90 | -- | 4.000 | 101.60 | 12.70 | -- | -- | P | -- | P | P | -- | |
22.20 | -- | 4.000 | 101.60 | 15.49 |
| |||||||
--
--
P
--
P
P
--
More details of products,you are welcome to contact me by mail,thanks!
4 1/2” | 12.60 | 12.75 | 4.500 | 114.30 | 6.88 | PNU | PNU | PNU | PNU | PNU | PNU | -- | 15.20 | -- | 4.500 | 114.30 | 8.56 | -- | -- | P | -- | P | P | -- | 17.00 | -- | 4.500 | 114.30 | 9.65 | -- | -- | P | -- | P | P | -- | 18.90 | -- | 4.500 | 114.30 | 10.92 | -- | -- | P | -- | P | P | -- | 21.50 | -- | 4.500 | 114.30 | 12.70 | -- | -- | P | -- | P | P | -- | 23.70 | -- | 4.500 | 114.30 | 14.22 | -- | -- | P | -- | P | P | -- | 26.10 | -- | 4.500 | 114.30 | 16.00 | -- | -- | P | -- | P | P | -- |
