Clay Graphite Crucible

FOB Price

USD $1 - $100 / Piece

1 Piece(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port Shanghai
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Type:	Refractory	Application:	melting metal, metallurgy, casting, chemical and (scientific) industry	Height:	78mm-1000mm
Composition:	High Pure	Top Diameter:	as per customers'request	Bottom Diameter:	as per customers'request
Place of Origin:	Shanghai, China	Brand Name:	Bochuan	Model Number:	BC-170

Product Description

Specifications

Clay Graphite Crucible
1.Material:high pure graphite
2.Used for metal melting
3.Long life and good property

Clay Graphite Crucible

1.Introduction

The material of graphite crucible can be divided into artificial graphite,clay bonded graphite, and carbon bonded graphite.Artificial graphite crucible is made of graphite electrode as material and made out.

Clay bonded graphite, the main ingredient is natural crystal graphite and clay Now only used in small amount of high-temperature melting of cast iron, cast steel melting and melting of precious metals.

Carbon bonded graphite, the main ingredient is natural crystal graphite and silicon carbide. Mainly used in the melting of the majority of non-ferrous metals such as copper alloy and aluminum alloy

2.Property

a. High thermal conductivity

b.Thermal shock resistance

c.High temperature resistance

d.Corrosion resistance

d. Mechanical shocks resistance

d. Oxidation resistance

e. Anti-adhesive

f. Small metal contamination

g. Good clearner

3. Shapes

standard type,long type,bowl type,lip type, electric furnace type

4.Purpose

melting of copper alloy and light metal alloy

5.Index

Standard parameter		Testing data
Refractoriness ≥	1630°C	Refractoriness≥	1635°C
Carbon connent ≥	38%	Carbon connent≥	41.46%
Apparent porosity ≤	35%	Apparent porosity ≤	32%
Bulk density ≥	1.6g/cm3	Bulk density ≥	1.71g/cm3

Specification	OD at top	Outer Height	OD at bottom
1000#	640	773	380
800#	630	720	335
500#	540	698	313
400#	520	648	282
350#	485	610	275
300#	470	573	240
250#	450	550	240
200#	398	490	220
150#	370	430	192
