Carbonated Drinks Bottling Machine

Specifications

Carbonated Drinks Bottling Machine
1. PET bottle and Glass Bottle Filling
2. 2000 - 20000bph
3. automatic PLC control
4.CE

Welcome your visit to Zhangjiagang Dingshun Machinery Factory!

Our company specialized in providing complete beverage line machinery for water,juice, carbonated beverage,alcohol and oil.



Carbonated Drinks Bottling Machine

Main Features



1).This Carbonated Drinks Bottling Machine is used to fill PET bottle carbonated beverage such as Coca-Cola, Pepsi-Cola,Sprite, Seven-Up, gas containing alcohol/juice and so on.



2). This Carbonated Drinks Bottling Machine has the functions of bottle washing, carbonated beverage filling, and bottle capping. This design reduce the time of liquid contact with outside. It improve the sanitation condition, increase the production capacity and economic efficiency.



3). It adpots hanging type conveying bottle structure to make changing different bottle sizes with less time and more convenient.



4).This Carbonated Drinks Bottling Machine use high quality food grade stainless steel material. All the material contact with liquid is Stainless Steel 304 (& stainless steel 316L according to customer's demands).



5).The whole machine is equipped with advanced PLC controlling system. Key electric elements is from international well-known brand such as MITSUBISHI, OMRON,SCHNEIDER.



6). This Carbonated Drinks Bottling Machine series can fill carbonated beverage from 2000bph to 20000bph.



DXGF series Carbonated Drinks Bottling Machine model and related information

Model:	DXGF12-12-4	DXGF14-12-5	DXGF16-12-6	DXGF18-18-6	DXGF24-24-8	DXGF32-32-10	DXGF40-40-12
Capacity (500ml based)	2000BPH	3000BPH	4000BPH	5000-6000BPH	7000-8000BPH	8000-10000BPH	10000-15000BPH
Suitable bottle :	Round bottle or square bottle
PET bottle: (mm)	(Bottle Diameter):φ50-.φ110mm   (Height):150-340mm
Suitable cap specification	PE screw cap
Filling precision:	≤±5mm
Filling pressure:(MPa)	≤0.4Mpa
Machine power	4.1	4.1	4.4	5.2	6.2	6.8	7.8
Machine size:(mm)	1900*1500*2300	2150*1650*2300	2250*1650*2300	2600*1965*2300	2980*2200*2300	3800*2200*2300	4250*3000*2300
Weight: (kg)	1800	2100	2500	3500	4500	5500	6800



Carbonated Beverage Filling Machine Picture





This DXGF series carbonated beverage filling  machine parts picture is as below



Rinsing                                                Filling                                                     Capping





Automatic Cap Supplying System



Production on spot



Machine Packing and Loading



Our factory and workshop



 Welcome your visit to our factory and build good business relationship with us!
