Fire alarm system: the SF-3000 series of analogue addressable fire alarm control panels marks a clear evolution from previous generations. This series has solutions to satisfy all market segments: from small domestic applications requiring 1 loop to large applications requiring 8 loops. At maximum configuration a SF system can support 30 control panels (arranged in a token-ring) and, if you consider that each control panel can manage up to 8 loops, and that each loop can accommodate as many as 240 devices, it is clearly apparent that the cutting-edge technology of the SF series has achieved excellence in application flexibility. The FS series has been specially designed to provide enhanced features, best-in-class performance, simple end-user operation and trouble-free installation, all with the aim of helping the installer company to improve efficiency. These first-rate features have been made possibile by the appliance of multiprocessor architecture with self-diagnosis features co-ordinated by a 32 bit processor. This impressive hardware podium provides the processing resources necessary to ensure the highest levels of reliability, response speed, ease-of-use, connection simplicity, enhancement opportunities and flexibility.
Order Codes:
SF-3001/P: Control panel with 1 loop, non-expandable, equipped with keypad, display and status LEDs. This model can be enhanced with a SmartLoop/PRN thermal printer.
SF-3002/P: Control panel with 2 loop, non-expandable, equipped with keypad, display and status LEDs. This model can be enhanced with a SmartLoop/PRN thermal printer.
SF-3208/P: Control panel with 2 loops expandable to 8, equipped with keypad, display and status LEDs. This model can be enhanced with a SmartLoop/PRN thermal printer.
SF-3001/G: Control panel with 1 loop, non-expandable, equipped with keypad and display.
SF-3002/G: Control panel with 2 loop, non-expandable, equipped with keypad and display.
SF-3208/G: Control panel with 2 loops expandable to 8, equipped with keypad and display.
SF-3001/S: Control panel with 1 loop, non-expandable, unequipped flush front.
SF-3208/S: Control panel with 2 loops expandable to 8, unequipped flush front.
Features and Technical specifications:
- Analog-addressable fire control panel - 2 loops expandable to 8 for 2080 expandable models 1 loop on non-expandable 1010 models - All models in the SF series are EN54 Approved - Multiprocessor hardware structure - 32 bit main CPU - OpenLoop Technology - HorNet token- ring architecture - Supports Emergency54 emergency configuration (CPU redundancy) - Manages up to 30 panel token-ring network via the SF/NET board (accessory item) - Easy remote access through SFLAN board (accessory item) - 2 or 4 wire loop connection - Supports 240 devices per loop - Manages up to 8 remote-control Repeater panels connected to the RS485 Interface - Manages power stations on the RS485 BUS - Manages a fire-suppression control panel on the RS485 BUS - 3 general purpose NAC outputs - 1 NAC Alarm output - 1 NAC Trouble output - 1 dry contact Alarm relay - 1 dry contact Trouble relay - RS485 BUS for Repeater panel connections extinguishing control panels via RS485 BUS RS485 BUS (maximum wire length between panels 1000m) - Manages up to 8 remote-control Repeater panels on the - 1 24 V power supply output for external devices - 1 24 V resettable output
| - Battery shutdown relay for deep discharge conditions - RS232 and USB connectors for uploading/downloading data - 2000 event buffer - Self-enrolling (for loop devices) - Self-addressing (for loop devices) - Manages conventional detectors (through SF/INOUT board) - Emergency phone call (through SF/PSTN board) - Large backlit alphanumeric display for easy management of Installer/User interface - Navigation keys for easy access to menu options - Fast keys (Test, Beeper, Silence, Reset, Evacuate, Investigate) - Beeper (provides audible signals) - User-friendly programming software (runs under Windows) - Easy system programming from the control panel - Code or key access to Level 2 functions (EN54 compliant) - On-board connector for Thermal probe (accessory item). - Battery efficiency test - Extensive application of SMD reflux technology for higher reliability - Plastics (for SF-3001/3002) or Metal box (for SF-3208) - Mains power supply 230Vac ± 10% - Switching power supply/battery charger 4A @ 27.6Vdc - Battery housing for two 17Ah, 12V batteries - Dimensions (HxWxD): 400x310x120mm - Weight (without batteries): |
