Home > Products > 2835 SMD LED Module > 12v SMD 2835 Mini led module for mini channel letter
12v SMD 2835 Mini led module for mini channel letter
- 1000000 Piece / Pieces per Month
- SHENZHEN
- Credit Card
- 5years warranty mini module 1pcs SMD 2835 led module for channel letter
- 12v 2chips SMD 2835 led module for light box
- Super bright SMD 2835 LED Module 0.72W 165 Degree Module LED
- 1 2 3 4 LEDs smd 2835 led module for mini channel letter
- High quality 2chips 2835 LED Module 0.72W 165 Degree
- High lumen LED module 2chips smd 2835 LED module for sign
Product Details
Model Number: | STF-T1 | Chip Material: | Other, Epsitar | Emitting Color: | Other, Pure white |
Luminous Intensity: | 2000-2500MCD | Luminous Flux(lm): | 35LM | Optical Attenuation(%): | 2 |
Power: | Other, 0.36W | Power Dissipation: | 0.36W | Color Rendering Index(Ra): | 85 |
Color Temperature: | 6000-6500K | Operating Temperature(℃): | -20, 60 | Storage Temperature(℃): | -20, 60 |
Place of Origin: | Guangdong, China | Brand Name: | singsun | Certification: | CE |
Product Description
12v SMD 2835 Mini led module for mini channel letter
LED Type | 2835 SMD LED |
LED BRAND | Epistar chip from Taiwan |
Viewing Angle | 165-170° |
Luminous Flux(lm) | 35LM |
LED Qty | 1 pcs |
Life Span | 50,000 H |
Working Voltage | DC12V |
Consumption | 0.36watt |
Driving Method | constant current |
Stand Length In Serial Connection | 50pcs |
Maximum Length In Serial Connection | ≤50pcs |
Shell | white ABS |
Dimension | 30*17*6.5 mm |
Available Color | W/WW/CW |
Certification | CE&ROHS |
Working Temperature | -20℃ —— +60℃ |
Store Temperature | -50℃ —— +60℃ |
IP Degree | IP65 |
50 pcs per string, 100pcs per bag, 5000 pcs per carton box. Carton size: 50*35*35 cm. Net Weight: 4.5 g/pc; 225 g/string; 24kg/carton.
Dimesion Diagram(mm):
1. For all your inquiries about us or our products, we will reply you in detail within 24 hours.
2. We own well-trained and passionate sales & after-sale services who can speak fluent English language.
3. We offer OEM services. Like print your own logo on product or customize the retail box packing ,etc.
4. We have very experienced R&D engineers and we have strong ability to do ODM projects.
Application:
This product is applicable for 3-20cm glowing character, advertisement board, light box or local lighting.
Shenzhen Singsun LED Co., Ltd, was founded in 2009, specialized in development & production of LED lighting products.We are engaged in research and development, production, marketing and service. Singsun LED has been one of the most excellent manufacturers in the LED field in Shenzhen, China.
We have dedicated in providing high quality advertisment lighting,perfect commercial lighting solution, We have owner design term and advance production equipments. Main products include LED module,LED strip,LED power supply, Rigid LED strip,LED controller,LED connector, etc, which are widely used in signage lighting, advertisting light decoration, advertisting liht box and commercial lighting area.
CE & RoHS Certifications:
Exhibition Pictures:
Russian REKLAMA 2014(Time: 23-26, September, 2014. Booth No: FC144) & 2014 Hong Kong International Lighting Fair Autumn Edition( Time: 27-30, October, 2014. Booth No: CR-A32)
Q1:Can I have samples to test ?
A:Yes, we are pleased to supply samples to test and check our quality.
Q2:Do you have any MOQ limited for order ?
A:Our MOQ for order is 5000 pieces.
Q3:What's the delivery time ?
A:Samples ;3-5 working days Mass production ;7-10 working day
Q4:What't the payment you accept ?
A: t/t(bank to bank payment)/paypal/western union
Q5:Do you offer guarantee for your products ?
A:Yes ,we offer 3-5 years guarantee fou our products ,during this period,any quality problem ,we can replace new for you.
Q6:How do you ship the goods and how long does it take ?
A:DHL/UPS/FEDEX/TNT;3-5days, by air flight ;5-7days ,by sea ;15-30days
