JH oil powered through-hole rotary hydraulic quick collet chuck for turret type cnc lathe machine
- 12106 Set / Sets per Month
- SHANGHAI QINGDAO NINGBO TIANJIN DALIAN etc.
- T/T L/C D/P D/A Credit Card PayPal
-
JHS oil powered open-center hydraulic Stationary Collet Chucks for turret type cnc lathe machine
-
JAS air powered open-center pneumatic Stationary Collet Chucks for turret type cnc lathe machine
-
through-hole single piston pneumatic cylinder
-
The Hollow Single Piston Rotary Cylinder
-
TK1075 Short Through-hole Rotating Lathe Power Chuck Oil Cylinder
-
TK852 Short Through-hole Rotating Lathe Power Chuck Oil Cylinder
Product Details
| Place of Origin: | Jiangsu, China | Brand Name: | IVY hydraulic collet chucks | Model Number: | JH7-40 hydraulic collet chuck |
| Power: | Hydraulic | Number of Jaws: | Other |
Product Description
JH oil powered through-hole rotary hydraulic quick collet chuck for turret type cnc lathe machine
Technical features:
6. Widely applied to convert manual lathe into powered ones.
7. Widely applied to build special purpose machines.
8. Do not spray cutting fluid to the chuck directly.
There are three questions to answer to aid the correct choice of power chuck:
1. Type and model of CNC lathe.
2. Length of workpiece?
3. Outer diameter of workpiece?
4. Processing requirement?
Size Parameters
| Model/Spec | A | B | C | D | E | F | G | H | I | J |
| JH5-25" | 135 | 100 | 26 | 4 | 105 | 45 | 68 | 115 | 74 | 3-M8 |
| JH7-40" | 192 | 155 | 46 | 5 | 125 | 65 | 95 | 172 | 74 | 3-M10 |
| JH7-70" | 192 | 155 | 69 | 5 | 139 | 105 | 126 | 172 | 89 | 3-M10 |
| JH9-90" | 230 | 190 | 89 | 6 | 110 | 105 | 136 | 210 | 96 | 3-M12 |
| JH9-120" | 230 | 190 | 120 | 6 | 160 | 140 | 275 | 210 | 105 | 3-M12 |
It is recommended to grease chucks at least twice a day in order to maximize longevity
Performance Parameters
| Model/Spec | Working pressure (kg/cm²) | Limit speed (rpm) | Clamping torque (mm) | Clamping stroke (mm) | Through-hole aperture | Max. chuck diameter | Net weight (kg) |
| JH5-25" | 10~25 | 1800 | 7 | 1.5 | Ø26 | Ø32 | 6.9 |
| JH7-40" | 10~20 | 1600 | 10 | 1.5 | Ø45 | Ø50 | 13.6 |
| JH7-70" | 10~20 | 1400 | 12 | 1.5 | Ø68 | Ø90 | 21 |
| JH9-90" | 10~20 | 1100 | 15 | 1.5 | Ø89 | Ø90 | 23 |
| JH9-120" | 10~18 | 900 | 18 | 1.5 | Ø120 | Ø132 | 32 |
The matching products including:
1. Connecting bolt
2. Vice jaw
3. Collet
