Different capacity belt oven dryer belt conveyor belt dryer machine price 008615515540620

Specifications

conveyor belt dryer machine
1.suit for different material
2.25 years experience.
3.ISO CE
4.Different capacity



                                                   conveyor belt dryer conveyor belt dryer machine

The mesh belt dryer is a kind of drying equipment for batch, continuous product; it is mainly used for drying different granular materials such as coal briquettes.charcoal briquettes.iron briquettes,carbon black briquettes,ect with better ventilation. The conveyor directly transports finished briquettes to the pallet conveyor, and the scraping plate on the upper end of the pallet conveyor arranges these balls evenly on the dryer, improving ventilation property of balls, achieving drying effect, ensuring continuous production of all equipment .







One Mainly technique for the conveyor belt dryer machine

Name: Mesh Belt Dryer;
Type: 20*3 ( 20 METER AND 3 LAYER);(size of  dryer will be custom-made as production demand)
Production capacity: 10 /h;
Power:22kw+11kw;
Dimension: 20.5*2.44*3.1m;
Weight:12ton;
Furnace size:1.75*1.75*5m;
Fuel Consume: coal as an example, 40-50kgph;
Temperature in side the dryer:150-200 degree;
Final Products Moisture Content: 2-3%;







features of  conveyor belt dryer machine
1. This dryer is made of 1Cr18Ni9Ti or SUS304 stainless steel plate; the conveyer belt is made of stainless steel chain or belt; and it adopts stepless speed regulation mechanism.
2. The heating component adopts FIR quartz heating device or gold plating quartz device equipped on the top of baker, where reflecting mechanism is also equipped to enhance heating efficiency.
3. The dryer is equipped with electric control cabinet and the temperature digital display system so that any constant temperature can be obtained.
4. It adopts Class-100 vertical purifying air to cool the material, which ensures the material under strict condition of bacterium and earth free.
5. The thermal insulation layer of oven adopts fine glass cotton and alumina support as the insulation material to guarantee good property of humidity preservation.





 Application:

The mesh belt dryer is a common continuous dryer equipment, it is widely applied in chemical,

foodstuff, pharmacy, construction material, and electronic industry, and particularly it is adapt to

 dry the raw materials which have good air permeability and shaped in sheet, strip or granule.

For ointment stuff, the wisest way to dry it are: shaped those stuff first, then drying it.





Picture show of conveyor belt dryer machine



Inside



Customer site



Delivery





If you are intested in our dryer.please feel free to contact us.
