CATV 5/8 ks pin type terminal
Negotiable
/ Piece
2000 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- shanghai
- T/T Credit Card
You May Like
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Dongbei | Model Number: | OPT-AP |
Type: | F | Application: | RF | Gender: | Male |
Product Description
Specifications
pin type terminal1) Wide bandwidth for use in broadband systems
2)O ring sealed watertight
3) ROSH,SGS
Connector type | 5/8 | Vibration | 100m/s2 (10~500Hz) |
Frequency Range | DC~1GHz | Durability(mating) | ≥500(cycles) |
Impedance | 75Ω | Temp.range | -25~+60°C |
Insertion Loss | < 0.3dB |
Material | Shell : Aluminium |
Power Capacity | > 20 A | Conductor: Brass,silver plating | |
| Internal ≤ 10 mΩ | ||
External ≤ 5 mΩ | Insulator: PTFE | ||
Insulating resistance | ≥ 1000 MΩ @DC500V | O Ring: Silicon Rubber | |
Withstanding voltage | 170V max | Applicable standard | IEC 60169-24 |
- Port terminators provide a 75 Ohm match to unused KS entry ports
- Wide bandwidth for use in broadband systems
- Standard pin length accommodates all amplifer and multitap mating requirements
- High return loss for excellent digital signal performance
- Superior power capability provides a minimum of 20 Amps current capacity on all connectors and adapters
- O-ring sealed for maximum enviromental protection,eliminating water migration
