Specifications
thermal silicone1.grey paste
2.for CPU/radiator/Heat Sink
3.thermal conductivity up to 3.5
4.1kg
Kafuter K-5213 3.5 w/m.k high thermal silicone grease
for LED Wall Lights/Spotlights/Bulbs
FEATURES
K-5213 is a high temperature thermal conductive silicone grease/paste/gel.
High thermal conductivity up to 3.5
Long working temperature (-50°c ~ +200°c)
Higher thixotropic, better elevation coating, and excellent stable properties
No toxic or corrosion, and not dry or dissolve.
APPLICATION
Potting and fixing in CPU, radiator (heat sink), aluminum and cooper substrates of PCB of electronics components in street lights, mine lamp, etc.
TYPICAL PROPERTIES
Product Name | K-5213 |
Appearance | grey paste |
Penetration(1/10mm,25°c) | 300~350 |
Proportion(g/cm3) | 2.9~3.1 |
Freeness(%.200°c,8h) | ≤2.0 |
Volatility(%.200°c,8h) | ≤2.0 |
Breakdown Voltage Strength (kV/mm) | ≤2.0 |
Thermal Conductivity(w/m.k) | ≥3.5 |
HOW TO USE
Preparation
Clean the coating surface and remove the oil and grease.
Application
Squeeze out the thermally conductive silicon grease, and directly coating into the uncoated surface with a thin layer.
The coating ways: brushing, scraping, or roll coating
Attention
The surface should coat evenly by filling the whole gap with a fully thin layer. And make sure not coat too much on the surface.
PACKAGING
1KG/tin
STORAGE
Store in cool and dry place, the shelf life is 18 months (≤25°c)
