Drive In Racks
- 1000 Set / Sets per Month
- Shanghai
- T/T Credit Card
-
Hot selling warehouse storage heavy duty racking ,drive-in racks
-
FILO Hot Selling Economical Warehouse, Drive-in racks systems
-
Hot sale warehouse storage drive-in pallet racking
-
high quality & very popular Drive in Pallet Rack Systems with ISO9001
-
Drive in Pallet Racks with ISO9001 warehouse rack
-
Drivr-in High quality warehouse racks
Product Details
| Place of Origin: | Shanghai, China | Brand Name: | Kanelson | Model Number: | K-007 |
| Type: | Selective Pallet Rack | Material: | Other, Q235b Steel/Spcc/SS400 | Feature: | Corrosion Protection |
| Use: | Warehouse Rack | Certification: | Other, CE,ISO9001 | Depth: | 1.5~2.5 |
| Weight Capacity: | Up to 3000kg/layer | Width: | 700-1200mm | Height: | 3000~10050mm |
Product Description
Drive In Rack
Introduction:
Drive in rack consist of upright frame, pallet rail, singal and double arm, top neam, back beam, singal and double side spacer, big and small top bracing, guide rail, upright protecter and so on. Pallet weight is no more than 1500kg, the good stake height on the pallet is no more than 2000mm. Drive in rack can make use of 75%of the warehouse space , is a kind of high density storage system. It can accomodate twice more pallets than pallet rack . Drive in rack is a kind of first in last out storage system, suits for the these goods which is of fast turnover, same kinds, unified and with long shelf-life.
1.materisl :Q235 steel/Spce/SS400
2.Origin:shanghai
3.4 layers
| Loading Capacity: | Up to 4,000 kgs UDL/level |
| Racking Height: | Up to 11,000mm |
| Racking Depth: | 700-1200mm |
| Beam Length: | Up to 3600mm |
| Racking Finish: | Powder Coated Finish or Galvanised Finish for Post & Bracing. |
| Raw Steel Code: | Q235 |
Specail sizes also avaiable to specific storage needs.
Heavy Duty Racking
Our Heavy Duty Racking is a most useful and cost-effective storage rack system providing direct access to all pallets. It provides high capacity storage, is easy to install and adjust.
It is designed to meet almost all pallet sizes or weight and suitable to be used with all types of lift trucks. A wide range of protection accessories is available, such as corner guards, column protector, back mesh, pallet support bar, etc. making storing a lot more safer.
Heavy Duty Racking Advantages:
Versatility and flexibility to meet any storage needs:
1) Pallets can be located, accessed and moved individually.
2) Infinitely adjustable and offering a wide range of options and components.
3) Maximizes space use in any warehouse configuration while retaining optimum product accessibility.
4) Strength and rigidity prevents compression damage to goods.
5) Bottom level of pallets can be stored on the floor, lowering structure costs.
Customized:
Please inform us the following information, we can provide the solutions as your requirment, thanks!
1) Size of the warehouse
2) Width, depth and height for each unit of rack
3) How many Levels for each unit of rack
4) Loading capacity for each pallet or for each level of beams
5) Color
Shanghai Kanelson logistics equipments co.,ltd. is specialized in the design and manufacture of all shelf systems. Over ten years efforts,we have completed thousands of projects,and formed the products series of various shelf. We will derive the international advanced technology,make the international first-class level,and improve our product structure fully, make the effort to improve the quality,reach the new level same as the internal markets and the synchronized development with the international market.
We will hand in hand research and develop cooperated with the famous scientific institution ,make the full inspection and testing to the shelf components based,research and analysis fully,provide the more reasonable ,scientific and safety reliable products and services to the market.
Parts:
Molds:
