Home > Products > Indoor LED Display > p2.5 smd full color indoor led circle display

p2.5 smd full color indoor led circle display

Name: p2.5 smd full color indoor led circle display
Brand: Proge indoor led circle display
Availability: InStock

FOB Price

USD $5,500 - $5,800 / Square Meter

1 Square Meter(Min.Order)

Supply Ability 50000 Square Meter / Square Meters per Month
Port Shenzhen

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Guangdong, China	Brand Name:	Proge indoor led circle display	Model Number:	PG-IFC-P2.5
Usage:	Indoor	Tube Chip Color:	Full Color	Display Function:	Video
Pixels:	Other, 2.5mm	Screen Dimension:	led circle display

Product Description

p2.5 smd full color indoor led circle display

Technical Parameters:

P2.5 Indoor High Definition Advertising LED Screen
S/N	Item	Technical Parameters
LED Parameters
1	Item Name	LED Type	Brightness	Wave Length	H/V Visual Angle
2	Red LED	SMD2121	120-140mcd	620-625nm	140º/60º
3	Green LED	SMD2121	360-435mcd	520-525nm	140º/60º
4	Blue LED	SMD2121	80-100mcd	470-475nm	140º/60º
Module Specifications
1	Pixel Pitch	2.5mm
2	Pixel Configuration	SMD3in1
3	Module Resolution	64 x 32 pixels
4	Module Pixles	2048 pixels
5	Module Size	160x160mm/160x80mm/240x240mm
Cabinet Specifications
1	Cabinet Size(W X H X D)	480mm x 640mm x 110mm
2	Cabinet Resolution(dot)	192 x 256 pixels
3	Module Quanity (pcs)	18pcs
4	Cabinet Pixels	36864 pixels
5	Pixel Density	160000 pixels/m2
6	Cabinet Materials	Iron or Aluminum
Whole Screen Specifications
1	Screen Brightness	≥1000cd/m2
2	Driving Method	1/32scan
3	Mini Viewing Distance	2.5m
4	Max. Power Consumption	2200W/m2
5	Average Power Consumption	880W/m2
6	Gray Level	8bits input, 4096 levels(212)
7	Display Color	16M
8	Frame Frequency	≥60Hz
9	Refresh Frequency	≥600Hz
10	Uninterrupted Working Hours	≥72 hours
11	Screen Life-span	≥50,000 hours
12	MTBF	≥5,000 hours
13	Discrete Blind Spot Rate	<1/10000
14	Continuous Blind Spot Rate	None
15	Blind Spot Rate	<1/10000
16	Screen Plainness	<±1mm
17	Power Supply Mode	AC220±10% 50Hz/AC110±10% 60Hz
18	Environment Temperature & Humidity	Temperature:-20 Celsius~+60 Celsius Humidity:10%~90% RH
19	Control Mode	Synchronous display with control PC by DVI
20	Control System	DVI video card + full color control card + fiber system( optional)
21	Display Content	Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
22	Interface	Standard Ethernet
23	Transmission Distance	Multi mode fiber <500m, single mode fiber <30km,internet cable <100m
