24 port steel case ethernet switch (WD-1024R)
Contact Person: Lucian | Phone: 86 186 8052 7431 | Skype: live:wifi2 | QQ: 1771612431
Widemac 24–port Fast Ethernet Switches are perfect for improving the performance of small to medium size networks. These switches satisfy the need for high-quality products at a very affordable price.
Our 24-port Fast Etherenet Switch is in 19” Small Rackmount design. It is targeted at workgroups, departmental or backbone computing environments at medium to large businesses. The aggregate bandwidth for this switch can reach up to 4.8Gbps. It can be placed near the core of the network to eliminate bottlenecks and improve the overall network throughout.
l 24 Port Ethernet Switch
l 100% Data filtering rate eliminates all error packets
l Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode
l Non-blocking switching architecture forwards and filters packets at full wire-speed for maximum throughput
l 4.8Gbps Switching Capacity
l Auto-MDI/MDIX eliminates the need for crossover cables
l Supports MAC address auto-learning and auto-aging
l Support the port N-Way Auto-Negotiation, Store and Forward
l Standard 19-inch small rack-mountable steel case
l Plug and Play design simplifies installation
l LED indicators for monitoring power, link, activity, 100Mbps
Standards and Protocols | IEEE802.3, 802.3u, 802.3x, CSMA/CD, TCP/IP |
Basic Function | Wire-speed Performance |
MAC Address Auto-Learning and Auto-aging | |
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode | |
Backbound Bandwidth | 4.8Gbps |
MAC Address Table | 8k |
Forwarding Rate | 10BASE-T: 14880pps/port |
Transmission Method | Store-and-Forward |
Ports | 24 10/100Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX) |
Network Media | 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) |
LED Indicators | Power, Link/Act, 100Mbps |
Safety & Emission | FCC, CE, RoHS |
Environment | Operating Temperature: 0°C~40°C (32°F~104°F) |
Power | 100-240VAC, 50/60Hz |
24 port switch
Contains:
1* 24 Port 10/100M Switch
1* Power Cable
1* User Manual
1* Mounting kit
Similar item:
WD-1024S
WD-1024D
A switch is a device that allows multiple computers to connect to one Internet connection. Unlike a network hub, which serves a similar purpose, a switch has the ability to manage the traffic that passes through it. A switch can be a stand-alone device, suitable for home or small office use, or rack-mounted for larger network applications. Switches also vary widely in traffic management capability. It's important to clearly define your requirements before you purchase a switch so you can buy the one best suited to your needs.
We are LG, D-Link, Telecom of Russia, Telecom of India, Skyworth, China Netcom and China Telecom’s OEM supplier. Have over 10 years of experience on research about WIFI cards, wireless adapter, wifi router with OPEN/DD -WRT, 3G router with print server outdoor router, CPE and Ethernet Giga Switch POE switch.
Contact person: Lucian |Tel: 86 186 8052 7431 |skype: live:wifi2 |QQ:1771612431
