Stone Coated Roof Panel Automatic Press Tiles Making Machine

Botou Golden Integrity Roll Forming Machine Co., Ltd.
Stone Coated Roof Panel Automatic Press Tiles Making Machine thumbnail-1
Stone Coated Roof Panel Automatic Press Tiles Making Machine photo-1
US$ 125,000 - 165,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tile Forming Machine
Tile Type:
Steel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
XINGANG TIANJIN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Tile Forming Machine
Tile Type Steel
Use Roof
Production Capacity 6pieces/min
Place of Origin Hebei, China
Brand Name JCX
Model Number stone coated
Power(W) 130kw
Voltage 380V 50hz three-phase
Dimension(L*W*H) 70m*1.4m*1.5m
Weight 35t
Certification TUV
Warranty 3 year, three year
After-sales Service Provided Engineers available to service machinery overseas

stone coated roof tile machine made in china,stone coated roll forming machine,roll forming machine

All the informations here including the specifications and the product pictures are based on the machine that we've export lately



Brief introduction

We developed this stone coated roof tile machine based on long time running and improvement. It is high-performance,stable, energy-efficient and easy operation.

It is including five main parts:

1. Auto bottom glue spraying section

2.Auto stone coated section

3 .The first time drying section

4 .Auto face glue spraying section

5. The second time drying section

Description:

No

Item

Description

1

 Auto bottom glue spraying section

Appearance size:4000*1000*2000          Unit:mm

Driving section:3KW Excitation motor or frequency speed regulation

(AS per  customers’requirements )

Automatic pressure spray tank:1set  capability:200kg   Range:0.6~1Mpa

Automatic glue machine motor: Servo motor, Power:750w, plc

Automatic spray gun:4 set(spare parts)

Dust collecting fan: 1set    power:200w

Damp proof lamp:1pc      power:100w

Conveying device:Chain reciprocating

Air compressor:1set   power:7.5kw

Dust control of axial flow fan:1set  power: 200w

Agitator: 1set   power:1.5kw

2

Auto stone coated section

Appearance size:3500×1000×1500         Unit:mm

Framework: Steel welding

Conveying device:Chain reciprocating

Automatic sand hopper: 1set  capability:200kg

Bucket lift:1 set

Manual sandblast gun:4sets

3

The first time drying section

Appearance size:25000×1000×1200           Unit:mm

Framework: Steel welding

Frame type thermal insulation wall: 1.2mm cold steel with Rock wool

Automatic temperature controller:4set  Range:0°~160°

Infrared heating tube: 30pcs   Power:30kw

Conveying device:Chain reciprocating

Air cooling device:1 set  Power:200w

4

Auto face glue spraying section

Appearance size:3000×1000×2000           Unit:mm

Framework: Steel welding

Damp proof lamp:1pc        Power:100w

Automatic pressure spray tank:1set  capability:200kg   Range:0.6~1Mpa

Conveying device:Chain reciprocating

Automatic spray gun:4 set(spare parts)

Manual patch glue gun:4 set

Dust control of axial flow fan:1set  power: 200w

Automatic glue machine motor: Servo motor, Power:750w

5

The second time drying section

Appearance size:30000×1000×1200           Unit:mm

Framework: Steel welding

Frame type thermal insulation wall: 1.2mm cold steel with Rock wool

Automatic temperature controller:4set  Range:0°~160°

Infrared heating tube: 30pcs   Power:30kw

Conveying device:Chain reciprocating

Air cooling device:1 set  Power:200w



Specifications:

No.

Item

Description

1

Working speed

6-10pcs/min

2

Main power

110kw

3

Electrical control system

PLC control system with famous brand

4

Dimension

65000x1500x1500mm

5

Driving mode

Chain

6

Temperature control

Automatic and constant temperature

7

Working time

Can be 24 hours

8

Workers

7 only

9

Time to dry

After come out from machine can be packed at once

10

Mold

Can be changed



Competitive Advantage:

Save electric, easy operation, stable, less labour, and quick change.

stone coated roof panel automatic press tiles making machinestone coated roof panel automatic press tiles making machinestone coated roof panel automatic press tiles making machine

stone coated roof panel automatic press tiles making machinestone coated roof panel automatic press tiles making machinestone coated roof panel automatic press tiles making machinestone coated roof panel automatic press tiles making machinestone coated roof panel automatic press tiles making machine

stone coated roof panel automatic press tiles making machine

Procurement Aspects

Procurement Aspects

Detailed Rule

Payment Terms

The payment shall be made by L/C or T/T ( 30% down-payment and the balance for 70% shall be paid before container loading at the seller`s factory when the buyer confirms the quality is up to the contracted requirements.

packaging

Suitable for sea transportation.Usually one High precision Grape stake roller formed facility loads in one container.Depends on the machine's size and weight.

Delivery Time

30-65days. Depends on the machine type.

After-sales Service

Warranty: 3 year warranty from date of shipment.
Guarantee:
1: Guaranteed against malfunctions due to manufacturing defects for 1 year after date of purchase. Repairs will be made free of charge.
2: Repairs will not be performed free of change even during the guarantee period in the follow circumstances
-  Damage occurs due to a natural disaster
-  Malfunction occurs due to user error
-  Malfunction occurs due to modifications
-  Malfunction occurs due to further movement or shipment after installation
3:Air ticket, transportation cost, hotel, meals and 50$ per day shall be for purchaser’s account if manufacturer’s engineer has to be send to purchaser’s factory to maintain the machine during the guarantee period.

Purchasing Process

fistly, send us the product profile. If it needs punching, please also send us the drawing of holes.
secondly, communicate with our professional salesperson on the technical details.
Thirdly, according to your requirements, our designers match you a right machine, and we will make you a quotation accordingly.
Fourthly, if you think it's necessary, you can visit our factory. In this way, you can see the machine at sght and communicate with our engineers.
fifthly, if you are satisfied with our machine and the price, then we will make the contract with each other officially.
sixthly, according to the contract, you pay the money and we ship the machine to you.



If you are tired of those Chinese bad machines, and want to buy high quality machines in China, Just stop searching!we are your best choice!We offer you quality machine with good price!
