4 Colors High Speed Flexo Printer Machine

Specifications

flexo printer machine
multicolor printing on plastic film tube, paper, nonwoven etc. roll material
print 1 to 4 colors

flexo printer machine

flexo printers



USE:
Introduce sentitization resin as flexible printing plate, suitable for printing such packing materials as polyethylene, polypropylene bag, cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.



Characteristics:
1.  Easy operation, flexible starting accurate colour register.
2.  The meter counter can set printing quantity according to the requirement. Stop the machine automatically at the set quantity or when the material is cut off.
3.  Lift and lower the printing plate cylinder manually, It will automatically stir the printing ink after lifting
4.  The printing ink is spread by the knurled cylindder with even ink colour.
5.  Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.  360 degree continuous and adjustable longitudinal register device.
7.  The imported frequency control of motor speed adapts to different printing speeds.
8.  There are inching/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.



Main Technical Parameters:

Model	YT-4600	YT-4800	YT-41000	YT-41200
Max. Material Width	600mm	800mm	1000mm	1200mm
Max. Printing Width	560mm	760mm	960mm	1160mm
Printing Length	220-910mm
Printing Speed	5-50m/min	5-50m/min	5-50m/min	5-50m/min
Max. Diameter of Roll Material	Φ450 mm
Total Power	9.8kw	10.5kw	11.2kw	12kw
Plate Thickness (including two-sided glue paper)	2.38mm
Machine Weight	3500kg	4000kg	4500kg	5000kg
Overall Dimension	4.5×1.6×2.4m	4.5×1.8×2.4m	4.5×2.0×2.4m	4.5×2.2×2.4m
Working Voltage	380V 3-phase 50Hz
Extra optional devices: 1) EPC web guider + Auto tension controller 2) Digital Corona Treater 3) Air Shaft
