Home > Products > Basket Mill > SC Basket Mill
SC Basket Mill
USD $1,500 - $7,890
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- Shanghai
You May Like
Product Details
| Condition: | New | Type: | Ball Mill | Product Type: | Paint |
| Place of Origin: | Shanghai, China | Brand Name: | ELE | Model Number: | EBMB |
| Certification: | CE,ISO | Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
EBMB Basket Mill
| Model | EBMB Hydraulic Lift Basket Mill | ||||||
| Power Supply | 380v, 50Hz,three phase ( can be customized) | ||||||
| Rotation Speed | 1500rpm | ||||||
| Speed Control | with inverter( Hongkong TTK) | ||||||
| Lift | hydraulic lift | ||||||
| Blade | SS304 stianless steel, inside of the basket is special composite materials structural components | ||||||
| Falsework | carbon steel,stainless steel | ||||||
| Application | Pesticide, Ink, Pigment,color paste, dye, | ||||||
| Features | 1.It integrates the dispersing and grinding process into one machine | ||||||
| 2.it is convenient to change the grinding material and less residual,saving the cost | |||||||
| 3.high grinding efficiency, even particle distribution,convenient hydraulic lifting, easy to maintain. | |||||||
More Detail Parameters
| Model | Suggested capacity | Power | Stroke | Dimention(L*W*H) | |
| L | KW | mm | |||
| EBM-7.5 | 30-100 | 7.5 | 900 | 1600×800×1900 | |
| EBM-11 | 60-200 | 11 | 1000 | 1800×800×2200 | |
| EBM-15 | 80-250 | 15 | 1000 | 1800×800×2200 | |
| EBM-18.5 | 100-350 | 18.5 | 1100 | 2200×900×2400 | |
| EBM-22 | 150-800 | 22 | 1200 | 2700×1100×2800 | |
| EBM-30 | 400-1000 | 30 | 1500 | 2800×1100×2800 | |
| EBM-37 | 800-1500 | 37 | 1500 | 3100×1300×2800 | |
| EBM-45 | 1200-2500 | 45 | 1500 | 3100×1300×2800 | |
Remarks
1.The motor can be explosion-proof
2.Can design jacket to heat and cool.
Basket Structure
