FJ Alcohol Blending Fermentation Tank/Potato Fermentation Tank

Specifications

FJ Fermentation Tank:
1.Stainless steel alcohol fermentation tank.
2.GMP/CE mini alcohol fermentation tank.

FJ Alcohol Blending Fermentation Tank/Potato Fermentation Tank

Descriptions:

1.The FJ Alcohol Blending Fermentation Tank/Potato Fermentation Tank is widely applied in pharmacy, fine chemical engineering and biological engineering industries. The tank body has interlayer and heat-insulating layer ( for heating, cooling or heat insulating) The tank body,upper and lower closure heads(or taper) all adopt spinning R-angle processing. The internal wall of the tank has got mirror polishing with finish Ra≤0.4μm.

2.It has no sanitary dead corner and its wholly-enclosed design ensures that materials are always mixed and ferment at non-pollution state.

3.It is equipped with devices including air respirator, cleaning ball, sanitation inlet , viewing

mirror, and viewing lamp. The fermentation process of Pharmacy, fine chemical engineering and biological products is aseptic and untainted.

4.Fermentation tank adopts aseptic system which helps avoid microorganism pollution in the air and greatly extends quality warranty period and purity of the products. We specially designed and installed aseptic respiratory air hole or aseptic normal-pressure fermentation system, which can finish circulating heat-up and cooling through medium heat-up and cooling. The parts that contact materials are all made of stainless steel SUS304 or SUS316L. Heat preservation adopts polyurethane blister or pearl cotton. External surface adopts sand grinding surface polishing treatment. All is in accordance with GMP standard. Volume has different specifications ranging from 100-20000L.



Main technical specifications:

specification	type	100L	200L	500L	1000L	2000L	5000L		10000L	20000L
Diameter mm)		400	500	700	900	1200	1500		1800	2300
Highly(mm)		2000	2300	2650	2900	3800	4480		5250	6550
pressure in the pot (Mpa)		0.2	0.2	0.2	0.2	0.2	0.2		0.2	0.2
Insert a set of pressures Mpa)		0.3	0.3	0.3	0.3	0.3	0.3		pipe0.3	pipe0.3
paddle is counted		2	2	2	2	2	3		3	4
Mix the rotational speed r/min)	80
power electrical machinery Kw)		0.55	0.75	1.1	1.5	3	5.5		7.5	7.5
Cool the way	Insert							arrange and manage



Mixing Type:



Tank Picture:
