806 – 2700 MHz Outdoor/ Indoor Directional Wall Mount MOMO Patch Panel DAS Antenna
AMXW-8027VS-8
Feature:
Exquisite appearance
Suitable for ordinary ceiling mounting
Optimized dimension
Vertical and Horizontal
Application: GSM/ CDMA/ PCS/ 3G/ WLAN/ 4G/ LTE/ WiFi system
AMXW-8027VS-8 Electrical Specifications | |||
Interface | Vertical | +45° | -45° |
Frequency range(MHz) | 806~960 | 1710~2690 | 1710~2690 |
Gain(dBi) | 4 | 7 | 7.5 |
Half-power beam width(°) | H:85 V:65 | H:75 V:55 | |
V.S.W.R. | ≤1.5 | ≤1.5 | |
Third-order Intercept Point(dBm) | ≤-97 | ||
Isolation between ports (dB) | ≥25 | ||
Cross-polar ratio(dB) | ≥15@0º ≥10@+/-60º | ||
Input Impedance(Ω) | 50 | ||
Polarization | Vertical and Horizontal | ||
Maximum input power(W) | 50 | ||
Lightning protection | DC Ground | ||
Input connector type | 2xN-Female | ||
Mechanical Specifications | |||
Dimensions(mm) | 260*170*60 | ||
Antenna weight(kg) | 0.72 | ||
Operating temperature(°c) | -40~60 | ||
Rated Wind Velocity(m/s) | 60 | ||
Radome material | ABS | ||
Radome color | white | ||
Waterproof Standard | IP54/ IP65/ IP67 | ||
Mounting way | wall-hanging or pole-holding | ||
Mounting pole hardware(mm) | 35~50 | ||
