AMEISON 5725 - 5850 MHz 18 dBi Wall Mount Flat Patch Panel 5.8g directional antenna
- 80000 Piece / Pieces per Month
- Shenzhen or HongKong
- T/T Credit Card PayPal
- AMEISON Directional Wall Mount Patch Panel dual-polarized 11 dBi CPE 4g antenna 800 mhz mimo
- AMEISON 14 dBi 1710 - 2170 MHz Directional Wall Mount Flat Patch Panel external 3g antenna for huawei e586es
- AMEISON 10 dBi 2300 - 2700 MHz Directional Wall Mount Flat Patch Panel antenna 4g huawei e5127
- AMEISON 2x11dBi 2500 - 2700 MHz wireless Directional MIMO Patch Panel CPE 2.5 2.7ghz antenna
- AMEISON 2400 - 2483 MHz Directional Wall Mount Flat Patch Panel 10 dBi 2.4GHz antenna zigbee
- AMEISON 7 dBi 806 - 960 MHz Directional Wall Mount Flat Patch Panel IEEE802.15.4 915MHz zigbee antenna
Product Details
Place of Origin: | Guangdong, China | Brand Name: | AMEISON | Model Number: | AMXW-5800-18 |
Packaging Details
bubble PP bag or EPE/inner box/master carton(safe export packaging) or others
Product Description
AMEISON 5725 - 5850 MHz 18 dBi Wall Mount Flat Patch Panel 5.8g directional antenna
AMXW-5800-18
Feature:
High gain, strong anti-interference ability
Good defense system
Full day working
Exquisite appearance
Optimized dimension
Application:
5.8 GHz WLAN Wi-Fi system
5.8 GHz ISM band
Public wireless hot spot coverage
AMXW-5800-18 Electrical Specifications | |
Frequency range(MHz) | 5725-5850 |
Bandwidth(MHz) | 125 |
Gain(dBi) | 18 |
Half-power beam width(°) | H:20 V:20 |
VSWR | ≤1.5 |
Input Impedance(Ω) | 50 |
Polarization | Vertical |
Maximum input power(W) | 100 |
Lightning protection | DC Ground |
Input connector type | N Female or Requested |
Mechanical Specifications | |
Dimensions-mm (Height/Width/Depth) | 225*195*47 |
Antenna weight(kg) | 0.8 |
Operating temperature(°c) | -40~60 |
Rated Wind Velocity(m/s) | 60 |
Radome material | ABS |
Radome color | white |
Waterproof Standard | IP54/ IP65/ IP67 |
Mounting way | wall-hanging or pole-holding |
Mounting hardware(mm) | 35 ~ 50 |
Company Profile
Shenzhen Ameison Communication Equipment Co.,Ltd.(AMEISON, Registered capital:RMB10,000,000 Yuan, around USD1,666,666.666) was established in 2009, is one of leading professional antenna designers, manufacturers and solutions suppliers in Shenzhen, China.
We are headquartered in Hong Kong with a number of production facilities in China.(Hong Kong Head Office: FOXTENNA COMMUNICATION LIMITED.)
AMEISON's main OEM/ODM products include 2.4/4.9/5.1/5.5/5.8GHz WLAN, Wi-Fi antennas; MIMO antennas; CPE antennas; GPS antennas; 1.5/ 2.6/ 3.5GHz WiMAX,fixed wireless access antennas; 3G, CDMA, GSM, PCS and McWILL base station antennas, repeater antennas; indoor distributed antennas; decorative antennas; TETRA antennas; VHF/UHF antennas; microwave antennas and passive components such as splitter, coupler, surge lightning protector etc.
Ameison offers responsible and professional service, quality antennas products with competitive cost and punctual delivery. Each product at Ameison is implemented through system with earnest quotation, well-planned, antenna design, precision testing making, and strict time-line control, QC and professional technical communication.
We accredited the certificate of ISO 9001:2008 issued from UKAS and IAF in 2012. We believe that we could further enhance our competitiveness and provide our best service to our customers.
With our strong technical know-how, advanced machineries, and high quality conscious, we can turn your design concept into a successful product.
Our Vision is:
To be the global antenna supplier/partner of choice for the defence, security and communications market.
Our Mission is:
We are committed to exceeding customer expectations through excellent and reliable service, and the prompt delivery of low-cost, high-quality products achieved through the integration of people, technology and key business systems.
Our mission is to become our customers' most valued supplier and maintain that status.
High-quality! Made In Shenzhen of China! Global Sharing!
To be a business partner with us now!
We welcome you to schedule a visit our factory and consult with us for more business benefits.
