Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Bulldozer > LD230 Lonking Brand China Track Bulldozer for Sale With Low Price
LD230 Lonking Brand China Track Bulldozer for Sale With Low Price
US$ 1 - 30,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Lonking
Model Number:
LD230
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LD230 China Brand New 24 Ton Bulldozer for Sale With Lonking Bulldozer PartsUS$ 1 - 30,000MOQ: 1 Unit -
LD230 Heavy Duty Lonking Brand Excavator for Sale With Low PriceUS$ 1 - 30,000MOQ: 1 Unit
-
LD230 China Brand New Style Big Bulldozer for Sale With Low PriceUS$ 1 - 30,000MOQ: 1 Unit
-
LD230 High Quality 24 Ton Bulldozer for Sale With Low PriceUS$ 1 - 30,000MOQ: 1 Unit
-
LD230 China Brand New Style 26 Ton Bulldozer at Low PriceUS$ 1 - 30,000MOQ: 1 Unit
Place of Origin
Shanghai, China
Brand Name
Lonking
Model Number
LD230
Condition
New
Moving Type
Crawler Bulldozer
Machine Weight
24000kg
Dimension(Long * Breadth * High)
7021x3510x3534mm
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Lonking 24 ton bulldozer for sale with low price for sale
the parameter for ld230
Engine | WD12G240E26 |
| Power | 175kW/1800rpm |
| Blade Type | Straight Blade |
| Operating Weight | 23500kg |
| Blade Capacity | 7.8m³ |
| Engine | |
| Model | WD12G240E26 |
| Type | Water-cooled, in-line, 4-Stroke,Direct Injection |
| Rated Power(kW) | 175 |
| Rated Speed(r/min) | 1800 |
| Number of Cylinders-Bore×Stroke(mm) | 6-126×155 |
| Piston Displacement(L) | 11.596 |
| Min.Fuel Consumption(g/kW·h) | 198.3 |
| Max.Torque(N) | 1250 |
| Water Tank Capacity(L) | 79 |
| Fuel Tank Capacity(L) | 580 |
| Hydraulic system | |
| Max Working Oil Pressure(MPa) | 14 |
| Oil Pump Type | Gear Pump |
| Flow(L/min) | 262 |
| Lifting Cylinder of Blade (Bore×Number of Cylinders) | Φ120×2 |
| Tilt Cylinder of Blade (Bore×Number of Cylinders) | Φ200×1 |
| Power Train System | |
| Type | Swing Type of Sprayed Beam Suspended Type of Balance Beam |
| Number of Carrier Rollers(Each Side) | 2 |
| Number of Track Rollers(Each Side) | 7 |
| Track Type | Single Grouser |
| Width of Shoe(mm) | 560 |
| Length of Track on Ground(mm) | 2840 |
| Blade | |
| Blade Type | Straight |
| Width×Height(mm) | 3725×1390 |
| Max.Lifting Height(mm) | 1210 |
| Max.Digging Depth(mm) | 542 |
| Cutting Edge Angle(°) | 55 |
| Max.Tilt(mm) | 735 |
| Ripper | |
| Type | Single-shank |
| Max.Penetration(mm) | 685 |
| Max.Lifting Height(mm) | 524 |
| Travelling Speed | |
| Speed of Forward Gears(km/h) | 0-3.6 |
| 0-6.5 | |
| 0-11.2 | |
| Speed of Reverse Gears(km/h) | 0-4.7 |
| 0-7.7 | |
| 0-13.2 | |
Size
(mm)
Product pictures
the pictures for Lonking bulldozer
