Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Compactor > High Quality 10 Ton Road Roller Price Cmd510B Lonking Brand
High Quality 10 Ton Road Roller Price Cmd510B Lonking Brand
US$ 1 - 10,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Single Drum Roller
Static Linear Pressure:
580N/cm
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CMD510B Lonking 10 Ton Road Roller for SaleUS$ 1 - 10,000MOQ: 1 Unit -
CMD510B China Brand New 10 Ton Road Roller for SaleUS$ 1 - 10,000MOQ: 1 Unit
-
CMD510B CHINA 10 TON ROAD ROLLER FOR SALE WITH LOW PRICEUS$ 1 - 10,000MOQ: 1 Unit
-
China Lonking 26 Ton Road Rollers for Sale With Low PriceUS$ 1 - 10,000MOQ: 1 Unit
-
CMD5033DD China Lonking 3 Ton Mini Road Roller for Sale With Low PriceUS$ 1 - 10,000MOQ: 1 Unit
Condition
New
Type
Single Drum Roller
Static Linear Pressure
580N/cm
Travel Speed
2.5-8.2km/h
Grade Ability
30%
Place of Origin
Shanghai, China
Brand Name
Lonking
Model Number
CMD510B
Power(W)
85kw
Dimension(L*W*H)
6398*2300*3096MM
Weight
10000kg
Certification
ISO CE
After-sales Service Provided
Engineers available to service machinery overseas
Lonking brand 10 ton road roller for sale
Product Description
lONKINGR 10TON ROAD ROLLER CDM510B FOR SALE
THE FEATURES FOR THE lONKING CDM510B PARAMETER
| Construction Machinery CDM510B features: |
| B SERIES SINGLE DRUM VIBRATORY ROLLERS |
| Front & Rear Light For Night Operation |
| Panoramic Cabin/Adjustbale Panel |
| Close-Loop Hydraulic Vibration System |
| Permco Hydraulic Components |
| Wear And Impress Resistant |
| A/C & Pad Foot Optional |
THE PAPAMETER OF lONKING10 TON ROAD ROLLER CDM510B
Size
| Weight Load | Model | CDM510B | |
| Operating Weight (kg) | 10000 | ||
| Distributed Weight for Drum(kg) | 5000 | ||
| Distributed Weight for RearWheel(kg) | 5000 | ||
| Compact Performance | Static Linear Load for Drum(N/cm) | 235 | |
| Frequency(HZ) | 28 | ||
| Nominal Amplitude(mm) | 1.8/0.9 | ||
| Centrifugal Force(kN) | 240/150 | ||
| Maneuverability Perfomance | Diameter of Drum(mm) | 1520 | |
| Width of Drum(mm) (W2) | 2120 | ||
| Rim Thickness of Drum(mm) | 20 | ||
| Length*Width*Height(mm)(L*W1*H) | 5975*2260*3250 | ||
| Min .Ground Clearance(mm) (h) | 420 | ||
| Min .Steering Radius(mm) | 6500 | ||
| Wheelbase(mm) (L1) | 3135 | ||
| Travel Speed(km/h) | Forward | 1.9/3.3/9.1 | |
| Reverse | 1.9/3.3 | ||
| Gradeability | 30% | ||
| Steering Angle | 30±1° | ||
| Swing Angle | ±10° | ||
| Tyre Specification | 17.5-25 12PR | ||
| Engine | Manufacturer | Yuchai | |
| Model | YC6B120-T20 | ||
| Rated Power(kW/rpm) | 85/2200 | ||
| Min Fuel Consumption(g/kW•h) | 235 | ||
| Capacity | Storage Battery (V/Ah) | 12V/120Ah/2 | |
| Fuel Tank(L) | 220 | ||
| Hydraulic Tank(L) | 220 | ||
| Others | Drive Type | Mechanical | |
| Vibration System | Open-loop Hydraulic Vibration System | ||
| Service Brake | Air Booster Caliper Rear Axle Brake | ||
| Parking Brake | Shaft Controlling Brake of Gear Box | ||
