Outline
3931A Quad FTA IRD is new cost effective design integrating 4 DVB-S IRDs and 4 TS decoders in one standard Unit rack space. Every single set can perform as a single FTA Satellite Receiver with MPEG-2 TS decoder. After demodulating or decoding, it outputs separate A/V signal and TS over ASI port. This modularized design largely saves the cost of the transport freight, the space of frame rack and power consumption. In general, it greatly optimizes the functionality and structure of the normal standard-alone FTA Satellite Receiver, providing users more convenient operating and maintenance experience.
Features
- 4 separate modules in 1U case, each module integrates an IRD and a decoder
- DVB-S Tuner input
- User-friendly and easy operating menu
- Editing all parameters of satellite and transponder
- OSD TV image-test (DVB ETS 300 706) and subtitle supporting
- Auto-switching PAL/NTSC
- Auto-saving the latest channel
- 4 to 4 Satellite Receiver module design, more compact in structure
Specifications
ASI Input | 4×BNC interface | |
Tuner Input | Interface | 4×input, 4×loop through output |
Input Level | -65~-25dBm | |
Input Frequency | 950~2150MHz | |
Symbol Rate | 2-45Msps | |
FEC Code Rate | 1/2, 2/3, 3/4, 5/6, 7/8QPSK | |
Video OUT | 4×2 CVBS (RCA interface) | |
Audio OUT | 4×Stereo Audio (L/R) | |
ASI OUT | 4×BNC interface | |
Miscellaneous | Dimension | 44mm×482mm×410mm |
Temperature | 0~45℃(Operating), -20~80℃(Storage) | |
Power | AC 90~220V, 50/60Hz, 25W | |
Principle Chart
CEKE has built a long-term and good R&D cooperative relationship with China North Industries Group 206 Institute, Guilin Institute of Automation Technology, Beijing University of Posts and Telecommunication and Guilin College of Aerospace Technology.
CEKE has passed the international ISO9001 Quality System Certification, and the digital television transmitter has passed the State Administration of Radio Film and Television (SARFT), SRRC,AQSIQ certification.
CEKE was awarded “Guilin National Microwave and Optical Communication High and New Technology Industrialization Base” by the Ministry of Science and Technology in 2011.
CEKE welcome customers sharing experience in our company, and we provide one week training for customers, including transmitter technology, engineering and maintaining regulations. We also can dispatch engineers overseas to install equipments, but customers should bear the cost of return-trip tickets, visa fees, accommodations, etc.
We are committed to provide customers with the most competitive price, one year free warranty period(Non-artificial damage) and maintenance for lifetime to enhance our long-term cooperation. For mutual benefit, we spare no efforts in satisfying our customer in every possible way.
