HFW barrier terminal block
- 900000 Piece / Pieces per Month
- NINBO
- T/T Credit Card
Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | JADE | Model Number: | FW4mm,6mm,10mm,12mm,14mm,16mm,20mm,25mm,30mm,35mm |
Product Description
Specifications
HFW barrier terminal block:1.Brass insert and Steel screw
2.Voltage:250- 400V
3.Current:3A-150A
4.Cable wire:2.5mm2- 45mm2
HFW barrier terminal block:
1. H,U(W),V(F) types
2.Material: made from PA, PE or PP.
3.The sizes: 4mm2,6mm2,10mm2,12mm2,14mm2,16mm2,20mm2,25mm2,35mm2,40mm2
4.Current: 3A, 6A, 10A, 15A, 20A, 30A, 60A, 80A, 100A, 150A
5.Colours: milk-white, black,transparent
6. Standard: IEC
7.Brass insert and Steel screw
8.Voltage: 250- 400V
9.Current : 3A - 150A
10.Cable wire : 2.5mm2 - 45mm2
11.Working Temperature : - 40oC to 110oC
Technical Data:
| Spec. | mm | ||
| Length | Width | High | |
| 3A-4mm2 | 96 | 14.8 | 12 |
| 3A-4mm2 | 88 | 15 | 11 |
| 6A-6mm2 | 106 | 18 | 14.5 |
| 6A-6mm2 | 102 | 17.5 | 13 |
| 10A-10mm2 | 120 | 19 | 13 |
| 10A-10mm2 | 110 | 17 | 13 |
| 30A-16mm2 | 162 | 24 | 23 |
| 30A-16mm2 | 158 | 21 | 15.5 |
| 60A-25mm2 | 195 | 33 | 25.5 |
| 60A-25mm2 | 174 | 26 | 22.5 |
| 80A-35mm2 | 226.8 | 36.1 | 29 |
| 100A-40mm2 | 250 | 40 | 33 |
| 150-45mm2 | 254.6 | 45 | 35 |
Contact Us
- Yueqing Jade Electric Factory
- Contact namecynthia Hu Chat Now
- Phone86-577-62751709
- AddressChangfeng Village, Liushi Town
-
