Electric Submersible Pump Cable 1AWG
- 1000000 Meter / Meters per Month
- FOB TIANJING OR OTHER HARBOUR
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | GaryLion | |
| Model Number | QYEQ-1AWG | Insulation Material | Rubber | |
| Type | Low Voltage | Application | Underground | |
| Conductor Material | Copper | Jacket | Other, Alloy Lead |
Product Description
Products and Technical Parameters
QYEQ Submersible Power Cable
Products Description
EPDM insulation, Inner lead sheath,Fiber tape covered completely over the lead sheath, Nitrile rubber jacket, Full galvanized steel (or Stainless steel or Monel) tape armour, Round type.
Production Range
Voltage: 3kV 4kV 5kV 6kV
Temperature: The permissible and long-term working temperature is 120℃(248℉).
Performing Criterion
GB/T16750-2008,API RP 11S6-2008
Application Range
The cable is applicable for using in Electricity Submersible Pump Units with rated voltage less than 3kV or 6kV. It has the excellent ability of oil-resistance, heat-resistance and corrosion-resistance.
Delivery & Packing
We use all steel corrugated reels with rapped fuming wood outside, the packing length is according to customers’ requirements, general minimum length is 1000 meters(3281 Feet); the cable are not allowed to knock against or twist, both ends should be moistureproof.
Cable’s Cross Section Chart
3
Specification and Parameters
Phase
| Cross Section mm2 | Conductor Diameter mm | DC Resistance at 20℃ ≤Ω/km | Insulation Thickness mm | Jacket Thickness mm | Overall Size and Weight | ||||||
3kV | 6kV | |||||||||||
Untinned | Tinned | 3kV | 6kV | 3kV | 6kV | mm×mm | kg/km | mm×mm | kg/km | |||
3 | 16 | 1/4.62 | 1.15 | 1.16 | 1.9 | 2.3 | 1.0 | 1.0 | 13×36 | 2211 | 13×38 | 2410 |
3 | 20 | 1/5.19 | 0.84 | 0.86 | 1.9 | 2.3 | 1.0 | 1.0 | 14×38 | 2442 | 14×40 | 2730 |
3 | 33.5 | 1/6.54 | 0.54 | 0.56 | 1.9 | 2.3 | 1.0 | 1.0 | 15×43 | 3116 | 15×45 | 3320 |
3 | 42.5 | 1/7.35 | 0.43 | 0.44 | 1.9 | 2.3 | 1.0 | 1.0 | 16×45 | 3544 | 16×47 | 3850 |
Index of Performance
Cross Section | Conductor Diameter mm | 3kV Insulation Resistance MΩ·km | 3kV Leakage Current at 15.6℃ μA/km/kV | 6kV Insulation Resistance MΩ·km | 6kV Leakage Current μA/km/kV | DC Voltage Test For 5 Minutes | ||
mm2 | AWG | 3kV | 6kV | |||||
16 | 5 | 4.62 | 1484 | 0.700 | 1692 | 0.607 | 27kV | 35kV |
20 | 4 | 5.19 | 1352 | 0.775 | 1548 | 0.656 | 27kV | 35kV |
33.5 | 2 | 6.54 | 1012 | 0.984 | 1170 | 0.853 | 27kV | 35kV |
42.5 | 1 | 7.35 | 919 | 1.083 | 1063 | 0.951 | 27kV | 35kV |
