High Quality 100N Tensile Testing Machine

Product Name :   100kn  Tensile Testing Machine

 Features:

lMeeting GB/T16491-2008, JJG139-1999 and GB/T8947-1998 Composite Plastic Woven Bags;

lAlso standards GB, ISO, ASTM, JIS, etc.

lAdopting single arm structure, with SCM auto control and data acquisition system, it realizes fully digital

      adjustment of data acquisition and control process. For tensile test, it can measure Max. test force, tensile

     strength, tearing strength, elongation strain, elogation and other technical indexes and can display many

       kinds of test curves, such as Force-Time, Deformation-Time and so on. After test, it can

lAutomatically calculate test data according to test parameters which are set before test and

      meantime display test results.

lUsing AC servo motor and ball screw drive loading, with stepless test speed. Adopting

      photoelectric encoder to measure tensile stroke, with features of even loading, stability,

      without impact, precise and reliable test data.

Application:

Applicable in plastic packing, plastics, petrochemical industry, printing industry and all product quality supervision departments, and also can be used for teaching demonstration in schools.

Specifications:

u  Model : LDS-1

u  Max. test force:  100N

u  Effective measuring range :2%-100%FS

u  Accuracy class : Class 1

u  Max. tensile stroke :800mm(can be changed as required)

u  Adjusting range of speed: 0.01-200mm/min

u  Accessories : Wave grips

Packing details:

Weight : About 120 Kg

Power supply: 220V/50HZ

Dimension   550 ×350 × 1450mm
