SIMCOM SIM7230E FDD LTE modules

SIM7230E

SIMCom presents an ultra compact and reliable wireless module SIM7230E which is based on Qualcomm MDM9225 multiple-mode LTE platform. SIM7230E is a complete multi-band LTE/HSPA+/HSPA/UMTS/EGDE/GPRS/GSM/GNSS PCIE module designed with very powerful processors integrating application core:ARMv7 Cortex™ A5(1GHz), dual Telecom core(Up to 500Mhz), Cortex-M3 core, allowing customer to benefitfrom small dimensions and cost-effective product solutions.Featuring an industry-standard PCI Express Mini Cardstandard with a USB 2.0 interface, the SIM7230Edelivers GSM/GPRS/EDGE/WCDMA/LTE-FDD performance for Data Transmission with low power consumption in high-speed Download and upload.

General features
•
Five-Band LTE-FDD 800(B20)/900(B8)/1800(B3)/2100(B1)/2600(B7) MHz
•
Tri-Band UMTS/HSDPA/HSPA+ 900(B8)/1800(B3)/2100(B1) MHz
Dual-Band GSM/GPRS/EDGE 900/1800 MHz
•
GPRS multi-slot class 12
•
EDGE multi-slot class 12
•
Output power

-UMTS 900/2100: 0.25W
-GSM900: 2W
-DCS1800: 1W
•
Control Via AT Commands or Gobi API
•
Supply voltage range: 3.3V
•
Operation temperature: -40°C to +80°C
•
Dimension: 51*30*4.55mm
•
Weight: TBD
•
LTE FDD/Rel-9 Cat4/Rel-10 Cat4
•
UTMS,
•
HSPA+ DC-HSPA+,Rel-10 HSPA+ including DCHSPA+MIMO and DCHSUPA
•
GSM GSM R99,GPRS,EDGE
•
GNSS gpsOne Gen 8B;standalone;assisted,XTRA;

Specifications for Data transfer
•
LTE
-Uplink up to 50Mbps,
-Downlink up to 150Mbps
•
HSPA+
-Uplink up to 11 Mbps,
-Downlink up to 42 Mbps
•
UMTS
-Uplink/Downlink up to 384Kbps
•
EDGE
-Uplink/Downlink up to 236Kbps
•
GPRS
-Uplink/Downlink up to 85.6Kbps
•
CSD

Other features
•
USB Driver for Microsoft Windows 2000/XP/Vista
•
USB Driver for Win7/Win8
•
USB Driver for Windows CE/Mobile
•
USB Driver for Linux 2.6/Android
•
USB Driver for MAC
•
RIL supporting for Android/Windows CE/Mobile
•
Automatic installation
•
Linux API SDK
•
Firmware update via USB
•
TCP/IP/IPV4/V6 Multi-PDP,MT PDP
•
FTP/FTPS/HTTP/HTTPS/SMTP/POP3/DNS
•
eCall Ready
•
Jamming detection support
•
Gobi SDK to the Win7/Win8/Linux
•
Source code of the PC manager of the device for reference
Interfaces
•
PCI Express Mini Card
•
USB 2.0

Certifications
• CE(TBD)
• ROHS(TBD)
• REACH(TBD)
• GCF(TBD)
