High Quality Electronic Circuit Board printing

Name: High Quality Electronic Circuit Board printing
Brand: Eastwin
Availability: InStock

FOB Price

USD $1.8 - $2.6 / Piece

1 Piece(Min.Order)

Supply Ability 1000 Square Meter / Square Meters per Month
Port Hongkong ; Shenzhen
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Guangdong, China	Brand Name:	Eastwin	Model Number:	PCB -EW89270
Number of Layers:	Other, 2-18layer	Base Material:	FR-4	Copper Thickness:	1oz
Board Thickness:	1.6mm	Min. Hole Size:	0.25mm	Min. Line Width:	0.003"
Min. Line Spacing:	0.1mm(4mil)	Surface Finishing:	HASL

Product Description

HIGH QUALITY ELECTRONIC CIRCUIT BOARD PRINTING,ELECTRONIC CIRCUIT BOARD, PRINTED CIRCUIT BOARD,CIRCUIT BOARD,PCB BOARD,PCB,PRINTED CIRCUIT BOARD, 94V0 PCB BOARD

EASTWIN OEM ONE-STOP ELECTRONIC ASSEMBLY MANUFACTURER

Professional Pcb & Pcba Manufacturer

PCB QUEST:

1.General info?

2.Company name?

3.Location?

4.Production facility?

5.Owned production?

6.Outsourcing?

7.PCB Design on customers request?

8.Software used?

9.Production capacity?

10.Accepting orders ?Delivery time?

11.Quotation response time needed?

12.Price level?

13.Quality Level?

14.Service Level?

15.Payment term?

16.Company advantages?

17.Disadvantages?

18.Reference

Check Answer in FAQ

Certifications

Our Services

PCB board products and PCB assembly services:

Multi-layer Board Application:Telecom,Computer Peripheral,Aero Industry.

Heavy Copper Board Application:Consumer,Telecom,Industrial Peripheral,Aero Industry

Copper Through Hole Application:Consumer

Silver Through Hole Application:Telecom,Computer peripheral

Single Side Board Application:Consumer,Telecom,Industrial,Aero Industry

Double Side Board Application:Consumer,Telecom,Industral,Aero Industry

Metal PCB Appli:Power Supply,ABS,Engine Control Module,Lighting Fixture,Backlight Module

Silver Jumper Application:Consumer,Telecom,Industrial Peripheral,Aero Industry

Carbon Jumper Application:Comsumer Peripheral,Telecom,Industrial,Aero Industry

Product Description

PRINTING CIRCUIT BOARD Technical Specification For PCB

Number of Layer	1,2,4 or 6,upto 18 layer
Order Quantity	1 to 50,000
Board Shape	Retangular,round,slots,cutouts,complex,irregular
Board Type	Rigid, Flexible, Rigid-flexible
Board Material	FR-4 glass epoxy, FR-4 high Tg, Rohs compliant,Aluminum,Rogers,etc.
Board Cutting	Shear,V-score,Tab-routed
Board Thickness	0.2-4.0mm, Flex 0.01-0.25mm
Copper Weight	1.0, 1.5, 2.0 oz
Solder Mask	Double-sided green LPI,Also support Red,White,Yellow,Blue,Black
Silk Screen	Double-sided or single-sided in white,yellow,black,or negative
Silk Screen Min Line Width	0.006'' or 0.15mm
Max Board Dimensions	20 inch20inch or 500mm500mm
Min Trace/Gap	0.10mm, or 4mils
Min Drill Hole Diameter	0.01'',0.25mm, or 10mils
Surface Finish	HASL,Nickle,Immersion Gold,Immersion Tin,Immersion Silver,OSP,etc.
Board Thickness Tolerance	±10%
Copper Weight Tolerance	± 0.25 oz
Minimal Slot Width	0.12'', 3.0mm, or 120mils
V-Score Depth	20-25% of board thickness
Design File Formate	Gerber RS-274,274D,Eagle and AutoCAD's DXF,DWG

PCB Assembly Capabilities

Quantity	Prototype&Low Volume PCB Assembly,from 1 Board to 250,is specialty,or up to 1000
Type of Assembly	SMT,Thru-hole
Solder Type	Water Soluble Solder Paste,Leaded and Lead-Free
Components	Passive Down to 0201 size BGA and VFBGA Leadless Chip Carriers/CSP Double-sided SMT Assembly Fine Pitch to 0.8mils BGA Repair and Reball Part Removal and Replacement
Bare Board Size	Smallest:0.250.25 inches Largest:2020 inches
File Formate	Bill of Materials Gerber files Pick-N-Place file
Types of Service	Turn-key,partial turn-key or consignment
Component packaging	Cut Tape,Tube,Reels,Loose Parts
Turn Time	Same day service to 15 days service
Testing	Flying Probe Test,X-ray Inspection AOI Test
PCB assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity Testing

Detailed Terms for Pcb Assembly

Technical requirement for pcb&pcb assembly:

----Professional Surface-mounting and Through-hole soldering Technology

----Various sizes like 1206,0805,0603 components SMT technology

----ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

----PCB Assembly With UL,CE,FCC,Rohs Approval

----Nitrogen gas reflow soldering technology for SMT.

----High Standard SMT&Solder Assembly Line

---- High density interconnected board placement technology capacity.
