Product Details
| Place of Origin: | Zhejiang, China | Brand Name: | YAHENG | Model Number: | HY-L15C |
| Type: | Other, Axle Scale, manual weight scale | Power Supply: | 220V/50HZ | Display Type: | LCD or LED, LCD |
| Rated Load: | 50t | Accuracy: | ±1/100, ±1/100 |
Product Description
Product Description
1.Light in weight, and convenient transportation.
2.Integral flat plate construction, high frequency in dynamic response,and high precision.
3.Applied special treatment, offering high protection class that are suitable for all kinds of environments.
4.Adopted special material in aero-industry, with good anti-over loading ability.
5.Assembled with rubber handles, avoided destroying of the handles
Output sensitivity (mV/V) | 1±0.2 | Temperature, compensated (°C) | -10~+50 |
Combined error (%ld) | 0.2 | Temperature, operating (°C) | -40~+80 |
Non-linearity (%ld) | 0.2 | Excitation, recommended (V) | 9~15DC |
Repeatability (%ld) | 0.1 | Excitation, max.(V) | 20DC |
Input resistance (Ω) | 3120±40 | Safe overload (%FS) | 120 |
Ouput Resistance (Ω) | 2800±10 | Ultimate overload (%FS) | 150 |
Insulation resistance(MΩ) | ≥5000(100VDC) | Protection class | IP66 |
Zero balance (%FS) | 4~10%FS | Cable Spec. | 4-wire shield cable |
Temperature effect on sensitivity (%FS/10°C ) | 0.1 | Max. load for single point (t) | 10 |
Temperature effect on zero (%FS/10°C) | 0.1 | Rated capacity (t) | 15 |
| Connections: Red Input(+) Black Input(-) Green Output(+) White Output(-) | |||
Detailed Images
1.Plastic box for weighing indicators;Standard carton for load cells;or request by client.
2.Delivery time according to the order quantity.
Company main products: wireless communication module , wireless , wireless loadometer weighing instrument / platform scale weighing system , direct explicit electronic crane scale , wireless electronic crane scale , wireless infrared remote control dynamometer , axle load scales , sensor detecting instrument , intelligent weighing control software , unattended weighing system and other products
1) When can I get the price?
We usually quote within 24 hours after we get your inquiry. If you are very urgent, pls call us or tell us in your email so that we will regard your inquiry priority.
2) How can I get a sample to check your quality?
After price confirmation, you can require for samples to check our quality. We will provide you sample for free (value under USD15), as long as you afford the express freight.
3) How long can I expect to get the sample?
After you pay the sample charges(if there is) and send us confirmed drawings, the sample will be ready for delivery in 3-7 working days. The samples will be sent to you via DHL, FedEx,UPS,TNT or EMS. It should arrive in 3-5 workdays. You can use your own express account or prepay us if you don't have any account.
4) What about the leading time for mass production?
Honestly, it depends on the order quantity. Normally, 15 days to 20 days after your deposit if no tooling needed.
