omputer -controlled Plastic injection machine

Injection section:

1. double guiding rod supporting
2. double cylinder balance injection
3. one-string hydraulic pressure mould setting
4. power seal single-cylinder push setting
5. super quality chrome molybdenum screw and barrel are processed by nitridation.

Computer-controlled:

   We use imported special purpose computer of injection molding. It’s processed and controlled by CPU. The execution speed of control system is improved and thus improves accuracy of machine and sensitivity of oil over-temperature alarm.

Hydraulic unit:

Hydraulic unit: Applied with imported advanced hydraulic components. System pressure is controlled through proportional valves. In addition, a quick mold clamping devices and fast-respond excellent control valves are also fitted on the unit.

Clamping unit:

Clamping unit: the design on five-point double toggle locking mechanism is optimized with adoption of computer. Finite-Element Analysis is applied to design the platens. Adjustable mechanical supporting system is used for moving platen to protect tie bars and prolong their lives. The unit also functions of low pressure mold protection with extra sensitivity.

mold:
