Automatic Ampoule Filling And Sealing Line

Specifications

1. from feedin to ultrasonic washing,drying and sterilizing
filling stoppering and capping
2.90 days delivery time

Product Characteristics:

      The compact line is consist of ultrasonic washing machine,circulating heated air sterilizing oven and liquid filling  stoppering machine , each machine can be used alone.

1. washing machine:

  1)Adopt mechanical gripper to hold the bottle in different size.

  2)Bottle washing is following one by one to insert into and water washing and air spraying is effective and saving water.

  3)The circulating washing  pipe and fine washing pipe is separated fitted,there is no cross-contamination

  4) Adding a buffering block before the spiral screw when access to the washing machine can  prevent ampoule broken and the spiral screw.

  5) Use export synchronous belt to conncect opener block to transfer bottles,make stable and reliable.

2. sterilizing and drying machine

  1) The oven use circulating heated air to heat,which can keep temperature even and energy-saving.

  2)The protection function device make the running safe when in sudden of power failure.

  3)Water cooling system is optional; it can decrease fresh air supply from the washing room ,and reduce the risk from the wind differential pressure imbalance ,achieve good cooling effect

  4)Wind differential pressure auto-balance system is optional ;it can decrease moving in heating section due to the pressure imbalance between room and oven.,and it can avoid series trouble ,such as the temperature increasing in filling room and washing room

3. filling stoppering capping machine

  1)The stopper part adopt  horizontal stopper feeding ,and horizontal disk stopper inhaling, which  is easy to observe and high speed feeding.

  2)The ceramic pump ,stainless steel pump , creeping pump is optional.

  3)If there no vial ,the machine can automatically stop filling and stoppering.

  4) Servo system is for optional for filling (Delta, Mitsubishi, Siemens)



Main Technical  Parameters:



bottle application	2-50ml GB standard vials
capacity	200-400vials/min
vials/ampoule qualified washing   rate	≥99%
vials/ampoule breaking rate while washing	≤0.1%
sterilizing temperature	300-350°C
filling error	≤±2%(volumetric pump,ceramics,stainless steel drived by by mechanical system)  ≤1%(volumetric pump drived by servo system)
qualified stoppering rate	≥99%
air laminar flow cleaness	100c
air displacement	100cbm/H(optional)
power	71KW
power supply	380V, 50HZ
gross weight	Approx. 6500KG
dimension	8357(L)×2248(W)×1900(H) mm
