Home > Construction & Decoration > Lock > Door Lock > CE Approval RFID Access Control System Long Rang Magnetic Card Reader
CE Approval RFID Access Control System Long Rang Magnetic Card Reader
US$ 28 - 50
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
VIANS
Model Number:
VI-MA20(EM card)/VI-MA21(MF card)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
125kHz Waterproof Door Keypad & Reader EH72US$ 45 - 48MOQ: 1 Piece -
IP68 Waterproof Door Keypad for Interior or Exterior Use MA10US$ 27 - 35MOQ: 1 Piece
-
Exterior 125khz Door KeypadsUS$ 40 - 45MOQ: 1 Piece
-
MA30 Hot Sale Wiegand Proximity Keypad 125kHzUS$ 42 - 48MOQ: 1 Piece
-
Vians Electric Waterproof Grade Fingerprint Access Control Keypad for Security SystemUS$ 47 - 49MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
VIANS
Model Number
VI-MA20(EM card)/VI-MA21(MF card)
CE approval RFID access control system long rang magnetic card reader
MA Door access control keypad is of single metal keypad, which is produced according to customer's requirements. Comparing with the common control keypads. It is one of the most leading single door access control keypads. It is not only has the function of the controller but aslo built in card reader, which is more convenient for using and installation.
Product Description
| Operating Voltage | 12V DC |
| User Capacity | 2000 |
| Card Reading Distance | 3-6 cm |
| Active Current | <60mA |
| Idle Current | 25±5 mA |
| Lock Output Load | Max 3A |
| Alarm Output Load | Max 20A |
| Operating Temperature | -45~60°C |
| Operating Humidity | 10%- 90% RH |
| Environment | Conforms to IP68 |
| Adjustable Door Relay time | 0 -99 seconds |
| Adjustable Alarm Time | 0- 3 minutes |
| Wiegand Interface | Wiegand 26 bit |
| Wiring Connections | Electric Lock, Exit Button,, External Alarm |
| Dimensions | L120 x W80x H25 mm |
Product Feature
- Waterproof, conforms to IP68
- Strong Zinc Alloy Electroplated anti-vandal case
- Full programming from the keypad
- 2000 uses, supports Card, PIN, Card + PIN
- Can be used as a stand alone keypad
- Backlight keys
- Wiegand 26 output for connection to a controller
- Adjustable Door Output time, Alarm time, Door Open time
- Very low power consumption (30mA)
- Fast operating speed, <20ms with 2000 users
- Lock output current short circuit protection
- Easy to install and program
- Built in light dependent resistor (LDR) for anti tamper
- Built in buzzer
- Red, Yellow and Green LEDS display the working status
