Home > Products > New Products > 220L blow moulding machine
220L blow moulding machine
USD $200,000 - $240,000
/ Set
1 Set(Min.Order)
- 35 Set / Sets per Month
- QINGDAO
- T/T
You May Like
Product Details
| Condition: | New | Application: | Bottle | Plastic Processed: | PE |
| Blow Moulding Type: | Extrusion Blow Moulding | Automatic: | Yes | Place of Origin: | Shandong, China |
| Brand Name: | Sehenda | Model Number: | SKJ | Voltage: | 350V |
| Power(W): | 180W | Dimension(L*W*H): | 5*3.5*2.8 | Weight: | 28 TON |
| Certification: | ISO9001, CE | Warranty: | 1 YERA | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.Energy Blow Moulding Machine2.Clamping force:900KN
3.Accumulator capacity: 25L
4.Dry cycle :280Pc/hr
5.High quality
220L blow moulding machine for water tank, loft tank, IBC tank
1. Appliction: 125-220L water storage tanks, checmicals tanks, IBC, pallet, septic tank, waste bin, road barrier, floating dock ect. which with layers 1 to 3.
2. Manpower: 2 new workers are enough for the whole production line, even both are female, and two weeks training are free of charge.
3. Output: 13-15 pcs/hour, with thickness 3.5 mm, also the weight and thickness can be adjusted by you from 1mm to 10 mm.
| Technical specification | ||||
| SKJ220L ONE LAYER | SK220L DOUBLE LAYER | SK220L THREE LAYER | ||
| Max. product volume | L | 220 | 220 | 220 |
| Screw diameter | MM | 130 | 100 | 100 |
| Screw L/D ratio | L/D | 30:1 | ||
| Screw drive power | KW | 110 | 55 | 55 |
| Screw heating capacity | KW | 26 | 33 | 45 |
| Screw heating zone | ZONE | 8 | 12 | 18 |
| Output | KG/H | 320 | 300 | 450 |
| Oil pump drive power | KW | 30 | ||
| Clamping force | KN | 600 | ||
| Mould open space | MM | 1800 | ||
| Mould thickness | MM | 920 | ||
| capacity | L | 23 | ||
| Die head capacity | KW | 30 | 35 | 40 |
| No. of heating zone | ZONE | 4 | ||
| Die head material | 38 CRMOALA(accumulator,lining,piston,die) | |||
| Control action | MITSUBISHI PLC | |||
| Blowing pressure | MPA | 0.6 | ||
| Cooling water pressure | MPA | 0.2 | ||
| size of machine | MM | 7000*3600*5400 | To be confirmed | To be confirmed |
| Weight of machine | MT | 18 | 24 | 27 |
Main unit
| LOW-VOLTAGE APPARATUS | LG | KOREA |
| PNEMATIV | AIRTAC | TAIWAN |
| HYDRAULIC COMPONENT | YUKEN | LAPAN |
| SEAL | DICHT0MATIK | GERMANY |
| OIL MOTOR | SIEMENS | |
| SCREW MOTOR | SINMENS | |
| PROXIMITY SWITCH | OMRON | JAPAN |
| PLC | MITSTUBLISH | |
| TOUCH SCREEN | WEINVIEW | TIAWAN |
| WALL THINKNESS CONTRAL SYSTEM | MOOG | JAPAN |
| FREQUENCY CONVERTERS | ABB/LG/MITSUBISH |
Contact Us
- Weifang Xinhengda Machine Co., Ltd.
- Contact nameJerry Liu Chat Now
- Phone86-536-7707777
- AddressSHIBU INDUSTRIAL PARK CHANGYI CITY Weifang,Shandong
