Automatic Lube Oil Filling Line/Oil Bottle Filling Capping Machine
- 1000 Set / Sets per Month
- Qingdao
- T/T L/C D/P D/A Credit Card PayPal
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Chemical, Food, Medical, Other, Chemical, Food, Medical, lubricating oil, edible oil | Packaging Type: | Barrel, Bottles, Cans |
Packaging Material: | Wood, Other, Wood, wooden box | Automatic Grade: | Automatic | Driven Type: | Pneumatic |
Voltage: | 220V/380V | Power: | 2.2KW | Place of Origin: | Shandong, China |
Brand Name: | Dongtai | Model Number: | ZLDG-6 lube oil filling line | Dimension(L*W*H): | 1500*780*1800mm |
Weight: | 200kg | Certification: | ISO; CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Product Name: Automatic Lube Oil Filling Line
Introduction
This series of oil filling line are widely used in filling a variety of oils and viscous liquids, such as peanut oil, blend oil, rapeseed oil and other edible oil filling.
Technical parameters
Filling speed: 1000-2000 (barrels / hour)
Filling capacity: 1-5L/ 0.1-1L/ >5L
Filling accuracy: ± ≤ 0.3% FS
Power Supply: 220/380V 3 phase +Earth Wire, 50 Hz
Pressure: 0.5-0.8Mpa
Humidity: <98 %
Ambient temperature: 0~40°C
Principle Features:
1.the advantage of flowmeter way: The adjustment in dosage is convenience and quick, the volume only need to be set on the touchscreen directly, considered that the vegetable oil is different in density in the different temperature, resulting in the volume setting different, we have added an automatic temperature-compensated system.
2.the accuracy of filling: instead of the tranditional computing type of flowmeter -- through pulse generator, now promoted by our company, the lube oil filling line adopting rotary encoder is more accurate.
3.the speed of filling: instead of the traditional power delivery -- pressure artesian flow, our lube oil filling line adopting frequency converter to adjust the speed of filling,the efficiency highly raised. The speed can be arbitrarily adjusted on panel.
4.the adjustment of filling accuracy, promoted by our company, the weight of filling can be set on the touchscreen.The lube oil filling machine carries on automatic conpensation system when error occurs.
5.each filling head’s speed of machine can be set on touchscreen.
nveyor belt be adjusted by frequency conversion
Device Configuration
The main engine is made of stainless steel.
The parts contact with material is made of 304 stainless steel.
Janpan Keyen Ce sensor
France Schnaid relay element
Taiwan Airtac pneumatic element
Mitsubishi PLC and frequency converter
Standard Export Packing for lube oil filling line
A.Cover by PVC film + fumigated wooden case;
B.Wooden case suitable for long distance ocean shipping.
Dongtai has a highly sophisticated technical talent, has a high- quality team, can in a timely manner to provide customers with comprehensive after-sale service.
No damage to human factors, all products one year warranty, life-long maintenance.
JINAN DONGTAI MACHINERY MANUFACTURING CO. , LTD. is a professional packaging machinery manufacturer. For many years, we have devoted great efforts on researching and developing products under DONGTAI & XUNJIE brand, making remarkable quality, especially in filling machine and packaging machine.
Our business involves various markets all over the world and in many fields is with our excellent product. Now we have been one of the biggest manufacturer of packing machine in northeast of China, and exported our products to 21 countries, such as USA, Holand, AE, Canada, Brazil, Russia, Austrilia, India and so on.On the basis of excellent quality and competitive price, you will be surely get a big success in your industry.
When inquiry, please provide detail packaging product name, volume range & packaging speed requirement. It will be convenient for us to recommend the most suitable machine to you. Any special, our company can be professional design to meet your requirements.
Your satisfaction is our greatest Pursuit. Believe Your Choice- Jinan Dongtai.
So What are you waiting for? Contact us, dear customers !
