Jacquard Stocking Machine

Specifications

knitting function:different choices of float line deck or all the knitting weaving,mesh,twill state tabby,add yam jacquard mesh.

 Computerized High Speed Jacquard stocking machine



Features:



1 Chinese and English display, large LCD display shows both character and figure.

2 Capacity of memory is 1M, can store many patterns.

3 Can input 2 patterns and 2 program files.

4 Computer control system can drive at most 6 ways of needle, 16 knives and 64 ways of air valve.

5 Pattern and program data can be input/ output by disk.

6 Equipped the UPS system can memory the current program and knitting action if transience power off. When the power restored, it can continue knitting to avoid any loss or wastage.

7 Password-protection for parameter setup, to avoid the inadvertent change or unallowed modification, improve the reliability and safety.





 knitting function:different choices of float line deck or all the knitting weaving,mesh,twill state tabby,add yam jacquard mesh,jacquard pattern.

Needles diameter :4''  4-1/2''

Needles&needle selectors: 192-480N,the second and forth braided lines use the eighth-grade pneumatic to select needle;the first and third braided lines use the 16th-grade pneumatic to select needle.

Machine power cost :1.5W

Electrical source :380V ;frequency 50/60HZ

Speed :450RPM(jacquard); the highest: 700RPM

Average output:pantyhose 350/24h ,short jacquard hose 600 pair /24h

Driving system :direct servomechanisms, synchronous belt drive

Weaving system ;different choice of elastic ribbon or be tabby 1*1,3*1 fixed meshes when all textile needles working,T-shape crotch secured with 1*1,each elastic ribbon can made in full wave state.

Opweation interface:display screen and keyboard inputting

Automatic stop: broken infrared

Fuel system: automatic fuel system
