process of making pure polar distilled water inc
- 100 Set / Sets per Month
- TIANJIN
Product Details
| Condition: | New | Application: | Distillation | Power Source: | Electric |
| Process: | Other, water disitller | Place of Origin: | Hebei, China | Brand Name: | Guanyu |
| Model Number: | DGJZZ-100 | Voltage: | 380V/50HZ | Power(W): | 72KW |
| Dimension(L*W*H): | 1320LX770WX2340H (mm) | Weight: | 200kg | Certification: | ISO9001 |
| Warranty: | 12 Months | After-sales Service Provided: | No overseas service provided |
Product Description
process of making pure polar distilled water inc
GuanYu company is a high-tech designing & manufacturing enterprise specializing in manufacturing water distiller machine for more than 10 years.The high effect water distiller machine possess national patent ,the patent NO.:98250961.8. Professional technology team can ensure the product and service’s quality .
modle parameter category | GJZZ -100 | GJZZ -200 | GJZZ -300 | GJZZ -400 | GJZZ -500 | GJZZ -800 | GJZZ -1000 | |
Distilled water Yield(L/H) | 100 | 200 | 300 | 400 | 500 | 800 | 1000 | |
Distilled water Temperature(°C) | 72-97 | 72-97 | 72-97 | 72-97 | 72-97 | 72-97 | 72-97 | |
Return water temperature (°C) | 70-95 | 70-95 | 70-95 | 70-95 | 70-95 | 70-95 | 70-95 | |
Cooling water Pressure(Mpa) | >0.1 | >0.1 | >0.1 | >0.1 | >0.1 | >0.1 | >0.1 | |
Cooling water consumption | 1:6 | 1:6 | 1:6 | 1:6 | 1:6 | 1:6 | 1:6 | |
Steam pressure (Mpa) | 0.15 | 0.15 | 0.15 | 0.20 | 0.20 | 0.25 | 0.25 | |
Steam consumption (Kg/H) | 102 | 204 | 306 | 408 | 510 | 816 | 1020 | |
Steam admission Pipe dia (mm) | 20 | 20 | 25 | 32 | 32 | 40 | 40 | |
Cooling water pipe Dia (mm) | 15 | 15 | 20 | 20 | 25 | 32 | 32 | |
Weight (kg) | 80 | 95 | 115 | 135 | 140 | 230 | 230 | |
Dimention
| Base dia (mm) | 500 | 500 | 500 | 600 | 600 | 560x650 | 560x650 |
Max dia (mm) | 700 | 700 | 700 | 800 | 800 | 1350 | 1350 | |
Height (mm) | 1450 | 1650 | 2000 | 2200 | 2400 | 2500 | 2600 | |
Water Distiller Filter UV Sterilizer
Compared with other disinfection forms, high effect water distiller machine has the following advantages:
Ø Long operating life
Automatic descaling when water scale reach 1 mm thick
Ø Saving steam
Consuming steam 102% under the pressure of 0.1-0.25Mpa, lower 18% than tower style
Ø Saving water
Cooling water ratio1:6, saving water 60% than tower style (1:14)
Ø Saving equipment
- Directly using well water or city tap water
- Compared to multiple effect water distiller machine , saving early
stage ‘s antiosmosis ( electrodialysis ),mixed bed and pretreatment equipment , greatly saving the cost .
Ø The quality of output water high
The conductivity of produced distilled water is in line with national standard <=2us/cm
