catv fttx fiber/fibre optical receiver ERH1085A

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 10000 Piece / Pieces per Month
Port SHANGHAI/NINGBO/SHENZHEN
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:

Zhejiang, China

Brand Name:

ERIC

Model Number:

ERH1085A

Product Description

catv fttx fiber/fibre optical receiver ERH1085A

Description :

ERH1000 Series product is designed for FTTH/FTTB or HFC applications. The general type ERH1085 has a normal

output level 85dBuV per-channel for TV. The enhanced type ERH1095 provide higher level, 95dBuV with -8dBm input power and 3.5% optical modulation index.

Feature

1.CATV FTTH AGC Fiber Optic Receiver
2.Good heat dissipation
3.Optical level control
4.Excellent ESD protect
5.With AGC function

Tech nical Specifications

Downstream signal path		General
Light Wavelength	1260 ~ 1600nm	Power Consumption	3.2W
Optical Input Power Range	-8 ~ +1dBm	Voltage	12V DC
Frequency Range	45MHz ~ 1GHz	RF Connector(s)	F Female
Output Level	90dBµV (AGC)	Optical Connector(s)	SC/APC
Flatness	±0.5dB	Dimensions(L×W×H)(mm)	100×80×28
Slope	0dB	Weight	0.2kg
Return Loss	16dB	Operating Temp.	-20 ~ 65°C
Noise Figure	48dB	ESD(RF) Port	2KV
CTB 59channels	≥60dB
CSO 59channels	≥60dB
