M20 M (Stair Tread) Diamond Stone Router Bit
- 10000 Piece / Pieces per Month
- Shanghai
- T/T L/C D/P D/A Credit Card
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | JDR | Model Number: | JDRRB-M20 |
Type: | Abrasive Disc | Size: | M20 |
Product Description
Specifications
1.Stair Tread nose granite router bits2. For shaping granite,marble,etc.
1. M20 M (Stair Tread) Diamond Stone Router Bit
2. Adopting the latest “Multilayer Vacuum Brazed Technology”, JDR Multilayer Vacuum Brazed Router Bits are the best bits on the market. Compared with the sintered router bits, they achieve a longer life and have much faster profiling on granites and engineered stones. These bits are versatile and will perform well, when used with water on most portable routers with speeds ranging from 5,000 to 11,000 RPM.
3.Both M8 and M10 bolts are included to fit all standard portable stone routers. It includes Position #1 bits in the most popular profiles: Full Bullnose, Demi-Bullnose, Ogee and etc. for 3cm(1-1/4”) or 2cm(3/4”) material. You can use our Monolayer Vacuum Brazed Router Bits as POS.#2 .
Postion | Type | Phase | Industrial speed process | High speed process | Stock removal | Spindel Speed | |||||
0 | Segmented | Profile shape | 400 to 600 mm/min | Up to 4000 mm | 0.5 mm | 4500 to 5000 RPM | |||||
1 | Con-rim | Roughing | 700 to 100 mm/min | Up to 5000 mm | 0.3 to 0.4 mm | 5000 to 5500 RPM | |||||
2 | Con-rim | Profiling | 1200 to 1500 mm/min | Up to 5000 mm | 0.2 to 0.3 mm | 4400 to 4600 RPM | |||||
3 | Con-rim | Finishing | 800 to 1000 mm/min | Up to 5000 mm | 0.2 to 0.1mm | 4400 to 4600 RPM |
. Knowlage of Multilayer Vacuum Brazed Technology:
Multilayer Brazed Diamond Profile Wheel, it looks like the traditional sintered product, but it is really different from the sintered product, because it is not made in a sintering machine. It is brazed in a vacuum furnace, the same as the singlelayer Diamond brazed Diamond Product, and many layer of diamond brazed inside the soft metal bond. The product has the thickness as sintered product and the bond hold diamond tightly, the crystals never been taken off when the tool works. In addition, because the bond is soft, the Multilayer brazed diamond tool is keeping more exposure all the time, thus it keeps with the fast cutting performance almost the same as the Monolayer Vacuum Brazed of Diamond tool and the life is much longer than sintered product. So that the Multilayer Vacuum Brazed Diamond Profile Wheel is suitable for all kinds of stone and it could be the best diamond product for the present.
JDR Diamond Tools Co., Ltd is backed up by Jiangyin Lingrui Diamond Tools Factory. , a leading manufacturer of electro-plated diamond saw blades, diamond polishing pads, diamond core drill bits, diamond hole saws,diamond files,diamond pins, diamond grinding wheels,diamond cup wheel,diamond router bits,diamond profiling wheels and other diamond tools in China which is located in the famous city of Jiangyin. To supply tools of the highest quality with the best possible service and to ensure that every tool offers unbeatable value, have been the simple objectives of our founders since 1999, and are the foundation stones of our business philosophy. Quality is the guiding principle for our highly experienced development team. Only when their quality is proven and guaranteed are the tools released for sale. By listening carefully to customers' feedbacks, continual product enhancements improve not only quality but also performance and ease of use. We provide not only tools, but also service. Our focus is on both production of foreign customers' requesting tools, and sourcing the right tools from China they need. Fast response to sample enquiries, rapid order processing and on time delivery ensures that customers' requirements are accurately and consistently satisfied, while this is guaranteed by years exporting experience in the field. Our company has a well deserved reputation for offering outstanding value. Our China-wide sourcing capability, together with in-house design and development facilities further contribute to ensuring that all JDR's tools set the standard for value. By the good quality and competitive price, as well as the best service, JDR's tools have reached all over the world.
