Computerized Multi-Needle Shuttleless Quilting Machine (BDNWS-1 Shuttleless)

Specifications

This machine is mainly used for quilting high-grade mattress panel ,bedding products and housing decoration etc...

Computerized Multi-Needle Quilting Machine



Main application and performance of computerized multi-needle quilting machine(shuttleless):

This machine is mainly used for quilting high-grade mattress panel ,bedding products and housing decoration etc, available with plentiful patterns .Its feature as: multi-span independent pattern(including 360°and 180°quilting pattern); auto stop for needle thread and hook thread ,auto needle positioner , CNC speed adjustor , CE certificated security protection system ,; strong steel machine base,high machine work speed ,stable ,less noisy ,no bump ; No change on presser board even if when panel fabric thickness changed much ; Latest computer controlling system ,precise quilting,no too much parameter setting ,neither pattern change in quiliting process .CAD drawing precise ,convenient and fast.Strong pattern combination and multi-span performance makes it available to quilting different patterns on different size mattress .Machine detector and indicator make it easily to be known .



Technical data of computerized multi-needle quilting machine(shuttleless):



Quilting width	2450mm
Needle bar spacing	50.8,76.2,127(5”);76.2,76.2,152.4(6”)
Needle hole distance	25.4
X stroke X	430
Max. thickeness	50mm (180°pattern)
Step length	3-6
Production speed	45~180M/h
Needle type	24/180, 23/160,22/140,21/130
Main shaft speed	650~930 rpm
Motor power	5.0KW
Voltage	380V/50Hz, 220V/60Hz
Machine weight	4000Kg
Machine size	L4715×W1200×H1925mm



Basic info:

Company name	Nanjing BCD Bedding Machinery Co., Ltd.
Country / region	China
add:	No. 10 Chenxu Rd., Chenguang Industry Area, Jiangning, Nanjing, Jiangsu, China
Postal code	211135
tel:	86-25-84198389
Fax:	86-25-51835247
Web site
Main Products	Mattress Machine, Tape Edge Machine, Mattress Handle Machine, Mattress Sewing Machine, Sofa Spring Machine, Mattress Tools



Description:

1. The primary source, short production cycle, product quality guaranteed.

2. We will provide a complete after-sales service, the machine packed in wooden cases.
