Home > Products > New Products > 10000L three layers blow molding machine
10000L three layers blow molding machine
- 100 Set / Sets per Month
- Qingdao port China
- T/T
Product Details
Condition: | New | Application: | Bottle | Plastic Processed: | PE |
Blow Moulding Type: | Extrusion Blow Moulding | Automatic: | Yes | Place of Origin: | Shandong, China |
Brand Name: | Yangkang | Model Number: | YK10000L-3 | Power(W): | 680kw |
Dimension(L*W*H): | 15mx13mx8.5m | Weight: | 180t | Certification: | SGS |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
- 1. Style Number: YK10000L-3 blow molding machine.
- 2. Product range:3000L—10000 L
- 3. Material process: HDPE
- 4. Output: 5 PC/H for 5000 L water storage tank with 75-90 kg.
- 5. Machine and Molds rate:
- 1. Payment Terms: FOB QINGDAO PORT,CHINA
30% deposit against the contract by T/T should be paid before the order;
70% balance should be paid off by T/T after inspection before delivery;
- 3. CONFIGURATION
PARISION CONTROL THINCKNESS CONTROL
MOOG
JAPAN
PLC
SEIMENS
GERMANY
TEMPERATURE CONTROL MODULE
SEIMENS
GERMANY
SERVO VALVE & SERVO TRANSDUCER
MIRAN
ITALY
INVERTER
SEIMENS
GERMANY
HYDRAULIC OIL SEAL
DZ
TAIWAN
INTERMEDIATE RELAY
OMRON
JAPAN
PNEUMATIC VALVE
AIRTECH
TAIWAN
HYDRAULIC PUMP & VALVE
YUKEN
JAPAN
PNEUMATIC SWITCH & CONTACTOR
SEIMENS
GERMANY
HYDRAULIC MOTOR & SCREW MOTOR
SEIMENS
GERMANY
REDUCER
GUOMAO
CHINA
9. AUXILIARY MACHINERY
COMMODITY
CAPACITY
SCRAP GRINDER
25 HP
AIR COMPRESSOR
30 HP
AIR TANK RECEIVER
8 CBM
COOLING TOWER
200 TON
MIXER
300 KG
10. OUTPUT FOR 5000 L BLOW MOLDING MACHINE:
Commodity
Output
Unit
Weight
Unit
3000 L Mould
6
PC/H
45-50
KG
3500 L Mould
6
PC/H
50-55
KG
4000 L Mould
5
PC/H
60-65
KG
4500 L Mould
5
PC/H
65-75
KG
5000 L Mould
5
PC/H
75-90
KG
6000 L Mould
4
PC/H
100-110
KG
8000 L Mould
4
PC/H
125-135
KG
10000 L Mould
4
PC/H
155-170
KG
DELIVERY TIME8 months after the down payment;
TRAINNING
The Buyer could dispatch their operators to the Seller’s factory for training, including machine operation, maintenance & simple repairs;
Or against the requests of the Buyer, the Seller’s technician could train the Buyer’s operators in the Buyer’s factory in the periods of installing & adjusting;
The training is free of charge;
INSTALLATION & ADJUSTMENT
The Seller could dispatch an engineer against the requests of the Buyer to install and adjust the machines for one week in the Buyer’s factory.
The Buyer should make a reservation in advance before delivery of the machines;
The Buyer should pay for the engineer’s food & board while installation in buyer’s factory.
GUARANTEE
The guarantee time is one and half yearafter the machines normally works in the Buyer’s factory, if only the problem is cause due to quality control or any reason by the Seller. We will supply replaced parts free of charge and our engineers will guide you how to solve the problems.
Any problem caused due to irregular operation or incorrect maintenance by the Buyer won’t be listed in guarantee coverage.
